神钢零件查询(4BD1) - ISUZU DIESEL ENGINE - K905 MARK II EXCAVATORS (1/06-12/07) (01-029) - STARTER (HITACHI) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
592 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | VI1811002231 | [1] | STARTER ASM, 12V-3-0KW | |
| . . | VI1811002232 | [1] | STARTER ASM, 12V-3.0KW | |
| 3. | VI5811210400 | [1] | ARMATURE ASM. | |
| 5. | VI5811291130 | [1] | BEARING, BALL | |
| 6. | VI5811291140 | [1] | BEARING, BALL | |
| 8. | VI5811291120 | [1] | WASHER KIT THRUST | |
| 13. | VI1811294680 | [1] | STOPPER SET, PINION | |
| 18. | VI1811295160 | [1] | COIL ASM., FIELD | |
| 20. | VI1811160450 | [2] | BRUSH, (+) | |
| 22. | VI1811151860 | [1] | COVER.REAR | |
| 24. | VI1811180420 | [1] | HOLDER ASM.BRUSH | |
| 25. | VI1811160450 | [2] | BRUSH, (+) | |
| 26. | VI5811170120 | [4] | SPRING, BRUSH | |
| 27. | VI1098002860 | [1] | BEARING ASM, CENTER | |
| 28. | VI5811291160 | [1] | SEAL, OIL | |
| 31. | VI1811291810 | [1] | SHAFT ASM, GEAR | |
| 33. | VI1811230310 | [1] | PINION ASM. | |
| 34. | VI1811510700 | [1] | SWITCH ASM. MAGNETIC | |
| 35. | VI1811292270 | [1] | COVER, TERMINAL | |
| 36. | VI1811130880 | [1] | CASE ASM, GEAR | |
| 37. | VI5811190120 | [1] | METAL GEAR CASE | |
| 38. | VI1811294690 | [1] | O-RING | |
| 39. | VI1811270420 | [1] | LEVER SET, SHIFT | |
| 43. | VI1811294700 | [1] | COVER SET, DUST | |
| 48. | VI5811291180 | [2] | BOLT, THROUGH | |
| 53. | VI1811294710 | [1] | PACKING | |
| 54. | VI1811710410 | [1] | SWITCH ASM. | |
| 61. | VI1811294740 | [1] | WASHER, SEAL | |
