神钢零件查询(4BD1) - ISUZU DIESEL ENGINE - K905 MARK II EXCAVATORS (1/06-12/07) (01-030) - STARTER (HITACHI) (P/N-181100-2231) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
162 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | VI5811001321 | [1] | STARTER ASM, 24V-3.7KW | |
| . . | VI5811002010 | [1] | STARTER ASM, 24V-3.7KW | |
| 5. | VI1811210200 | [1] | ARMATURE ASM. | |
| 7. | VI1811291430 | [1] | STOPPER SET, PINION | |
| 14. | VI5811290030 | [1] | WASHER SET.THRUST | |
| 22. | VI1811120140 | [1] | COIL ASM, FIELD | |
| 25. | VI1811160170 | [2] | BRUSH, (+) | |
| 30. | VI5811150130 | [1] | COVER ASM, REAR | |
| 32. | VI5811190120 | [1] | METAL, REAR | |
| 33. | VI5811180020 | [1] | HOLDER ASM, BRUSH | |
| 35. | VI5811170060 | [4] | SPRING, BRUSH | |
| 37. | VI1811160180 | [2] | BRUSH, (-) | |
| 50. | VI1811291440 | [1] | BEARING ASM, CENTER | |
| 52. | VI1811291450 | [1] | METAL, CENTER | |
| 55. | VI5811230190 | [1] | PINION ASM. | |
| 65. | VI5811130290 | [1] | CASE ASM, GEAR | |
| 66. | VI1811291460 | [1] | METAL, FRT. | |
| 67. | VI1811291480 | [1] | COVER SET, DUST | |
| 75. | VI1811270190 | [1] | LEVER ASM, SHIFT | |
| 80. | VI1811510290 | [1] | SWITCH ASM, MAGNETIC | |
| 80-1. | VI5811510570 | [1] | SWITCH ASM, MAGNETIC | |
| 84. | VI5811290110 | [2] | BOLT, CASE | |
| 85. | VI1811291470 | [2] | BOLT, THROUGH | |
| 86. | VI5811290730 | [1] | WASHER, THROUGH | |
| 90. | VI1811710190 | [1] | RELAY ASM, STARTER | |
