神钢零件查询(4JB1) - ISUZU DIESEL ENGINE (1/06-12/07) (01-039) - CLUTCH & SLAVE CYLINDER Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
756 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VI8942591321 | [1] | PLATE ASM,PRESSURE | |
| 1. | VI5312200021 | [1] | PLATE ASM,PRESSURE | |
| 1. | VI5312200170 | [1] | PLATE ASM,PRESSURE | |
| 2. | VI8970135480 | [1] | DISC ASM,CLUTCH, NON ASB. | |
| 2. | VI8970109500 | [1] | DISC ASH,CLUTCH | |
| 2. | VI8970426820 | [1] | DISC ASM,CLUTCH | |
| 3. | VI9098785320 | [2] | PIN,STRAIGHT | |
| 3. | VI9081510250 | [3] | PIN | KOBSTRAIGHT Superseded by part number: 86987422 |
| 4. | VI8943218401 | [6] | BOLT,PLATE FIX. | |
| 4. | VI0280808160 | [6] | BOLT,(96-12-) | |
| 4. | VI0500408180 | [6] | BOLT | KOBBOLT,PLATE FIX. Superseded by part number: VI0505408180 |
| 5. | VI5093640963 | [1] | HOSE,FLEX..CLUTCH | |
| 6. | VI9099208731 | [1] | GASKET,FLEX. HOSE | |
| 7. | VI5475700201 | [1] | CYLINDER ASM,SLAVE | |
| 7. | VI8943193041 | [1] | CYLINDER ASM,SLAVE | |
| 7-1. | VI8970242931 | [1] | CYLINDER ASH,SLAVE | |
| 8. | VI5093320120 | [1] | BOOT,SLAVE CYL. | |
| 8. | VI8944578590 | [1] | BOOT,SLAVE CYL. | |
| 9. | VI8941151130 | [1] | SCREW,BREEDER | |
| 9. | VI9476150081 | [1] | SCREW,BREEDER | |
| 10. | VI9476190050 | [1] | CAP CAP,BLEEDER | CAP CAP,BLEEDER |
| 11. | VI9834613020 | [1] | ROD,PUSH,SLAVE CYL. | |
| 11. | VI8944596980 | [1] | ROD,PUSH.SLAVE CYL. | |
| 11. | VI9834617060 | [1] | ROD,PUSH,SLAVE CYL. | |
| 12. | VI9091114080 | [2] | NUT | KOBNUT,PUSH ROD |
| 13. | VI9096440050 | [1] | NUT,ADUST.PUSH ROD | |
| 14. | VI9313490100 | [1] | ROD END,SLAVE CYL. | |
| 16. | VI0500408300 | [2] | BOLT | KOBBOLT,SLAVE CYL.FIX. Superseded by part number: VI0505408300 |
| 16. | VI0108058400 | [2] | BOLT,SLAVE CYL.FIX. | |
| 17. | VI9091605080 | [2] | WASHER | KOBWASHER,PL |
| 18. | VI9091505080 | [2] | WASHER | KOBWASHER,SPR. Superseded by part number: VI0915105080 |
| 19. | VI9091104080 | [2] | HANGER | KOBNUT Superseded by part number: VI0911105080 |
| 20. | VI9313490130 | [1] | PLATE,ANCHOR, LEVER | |
| 20. | VI5313490011 | [1] | PLATE,ANCHOR.LEVER | |
| 21. | VI9099423201 | [1] | SPRING,RETURN.W/LEVER | |
| 21. | VI5095830401 | [1] | SPRING,RETURN,W/LEVER | |
| 21. | VI8944599240 | [1] | SPRING,RETURN,S/FORK | |
| 22. | VI8941083602 | [1] | HOSE,FLEX..S/CYL. | |
