神钢零件查询(4JB1) - ISUZU DIESEL ENGINE (1/06-12/07) (01-043) - PARKING BRAKE Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
877 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VI9462006016 | [1] | BRAKE ASM,CENTER | |
| 2. | VI9462136012 | [1] | PLATE,BACK,CENTER BRAKE | |
| 3. | VI5462200012 | [2] | SHOE ASH,W/LINING | |
| 4. | VI8941287650 | [1] | LEVER ASM,HAND BRAKE | |
| 6. | VI9463490051 | [1] | RETAINER'.PIN,CENTER BRK. | |
| 7. | VI5462510070 | [1] | STRUT,CENTER BRAKE | |
| 8. | VI9099425211 | [1] | SPRING,STRUT,CENTER BRAKE | |
| 9. | VI9099425521 | [1] | SPRING,RETURN,PRIMARY | |
| 10. | VI9099425531 | [1] | SPRING,RETURN. SECONDARY | |
| 11. | VI5471650250 | [1] | SCREW ASH,ADJ.CENTER BRK | |
| 12. | VI9099423401 | [1] | SPRING,ADJ.SCREW | |
| 13. | VI9099410621 | [2] | SPRING,SHOE HOLD | |
| 14. | VI9471620340 | [2] | PIN,SHOE HOLD,CENTER BRK. | |
| 15. | VI8943784040 | [2] | CUP,SHOE HOLD,CENTER BRK. | |
| 16. | VI5461510734 | [1] | CABLE ASH,HAND BRK.RR. | |
| 18. | VI9091854120 | [1] | SNAP RING | KOBRING,SNAP,CABLE FIX. |
| 19. | VI0500408140 | [2] | BOLT,BACK PLATE - MISSION | |
| 20. | VI9991105120 | [1] | NUT | KOBNUT |
| 21. | VI9091505120 | [1] | LOCK WASHER | KOBWASHER,SPR. |
| 22. | VI5462100053 | [1] | DRUM,CENTER BRAKE | |
| 24. | VI5423190030 | [1] | COVER,DRUM,ADJ.HOLE | |
| 25. | VI0500406160 | [1] | SPECIAL BOLT | KOBBOLT,COVER TO BRAKE DRUM Superseded by part number: VI0505406160 |
| 26. | VI9091105100 | [4] | NUT | KOBNUT,BRAKE DRUM FIXING |
| 27. | VI9091506100 | [4] | WASHER | KOBBASHER,SPR. |
