神钢零件查询(4JB1) - ISUZU DIESEL ENGINE (1/06-12/07) (01-063) - GENERATOR (NIKKO) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
938 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | VI8970222112 | [1] | GENERATOR | KOBGENERATOR ASM,24V-30A Superseded by part number: VI8972251970 |
| 1. | VI8970290540 | [1] | ROTOR ASM. | |
| 2. | VI8941730550 | [1] | COLLAR | |
| 3. | VI8941730560 | [1] | COLLAR | |
| 4. | VI8941730600 | [1] | RETAINER | |
| 5. | VI8941730540 | [1] | BALL BEARING | KOBBEARING BALL |
| 6. | VI8941730570 | [1] | COLLAR | |
| 7. | VI8970290550 | [1] | STATOR | KOBASM. |
| 8. | VI8943822770 | [1] | BRACKET,FRT. | |
| 9. | VI8943388650 | [1] | RETAINER | |
| 10. | VI8941730590 | [1] | RETAINER | |
| 11. | VI8943390420 | [1] | PACKING | |
| 12. | VI1812292790 | [1] | BALL BEARING | KOBBEARING,BALL Superseded by part number: 1812292790 |
| 13. | VI1812293820 | [3] | BOLT | KOBBOLT |
| 14. | VI8941730510 | [1] | PULLEY | KOBPULLEY ASSY Superseded by part number: 8941730510 |
| 15. | VI8941730700 | [1] | FAN | KOBFAN Superseded by part number: 8941730700 |
| 16. | VI8941730800 | [1] | NUT | |
| 17. | VI1812294790 | [1] | WASHER | KOBWASHER,SPR |
| 18. | VI8970290560 | [1] | BRACKET ASM,REAR | |
| 19. | VI8943822790 | [1] | BRACKET,REAR | |
| 20. | VI8970290570 | [1] | RECTIFIER | KOBASM. |
| 21. | VI8944379220 | [2] | BRUSH | KOBBRUSH |
| 22. | VI8970290580 | [1] | TERMINAL ASM. | |
| 23. | VI8943822820 | [1] | BOLT | |
| 24. | VI8941730610 | [1] | BUSH,INSULATE. | |
| 25. | VI1812295440 | [1] | COVER | |
| 26. | VI1812291220 | [1] | CLIP | |
| 27. | VI1812295200 | [1] | BUSH | |
| 28. | VI1812700150 | [1] | REGULATOR | KOBREGULATOR ASSY |
