神钢零件查询(4JB1) - ISUZU DIESEL ENGINE (1/06-12/07) (01-064) - GENERATOR (MITSUBISHI) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
1026 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | VI8971433290 | [1] | GENERATOR ASK. ,24V-20A | |
| 1. | VI8971453270 | [1] | NUT | KOBNUT |
| 2. | VI8971447390 | [1] | PULLEY ASM. | |
| 3. | VI8971453280 | [1] | BOLT | KOBBOLT |
| 4. | VI8971447260 | [1] | BRACKET ASM,FR | |
| 5. | VI8971447270 | [1] | SCREW | KOBSCHREW SET |
| 6. | VI8971447400 | [1] | BEARING | KOBBEARING,BALL FRONT |
| 7. | VI8971447280 | [1] | ROTOR ASM | |
| 8. | VI8971447410 | [1] | BEARING | KOBBEARING,BALL RR |
| 9. | VI8971447320 | [1] | STATOR ASM | |
| 10. | VI8971447360 | [1] | BRACKET ASM.RR | |
| 11. | VI8971447370 | [1] | RECTIFIER ASM | |
| 12. | VI8971455160 | [1] | NUT | KOBNUT SET |
| 13. | VI8971447420 | [1] | IC REGULATOR SET | |
| 14. | VI8971447380 | [2] | BRUSH | KOBBRUSH SET |
