神钢零件查询(4JB1) - ISUZU DIESEL ENGINE - K903C EXCAVATOR (1/06-12/07) (01-008) - VALVE MECHANISM ( CAM SHAFT, IDLE GEAR, ROCKER ARM) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
558 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VI8941277971 | [1] | CAM SHAFT | |
| 3. | VI8944020050 | [1] | GEAR ASM., CAM | |
| 3. | VI8944288020 | [1] | GEAR ASM., CAM | |
| 3. | VI8941104791 | [1] | GEAR, CAM | |
| 4. | VI8944020060 | [2] | PLATE, TACHO SENSOR | |
| 5. | VI9020506120 | [4] | BOLT, PLATE | |
| 6. | VI9091505060 | [4] | WASHER | KOBWASHER, SPR. |
| 7. | VI9080007180 | [1] | KEY | KOBKEY, FEATHER |
| 8. | VI5090000690 | [1] | BOLT | KOBBOLT |
| 9. | VI5125190021 | [1] | WASHER | KOBWASHER, CAM GEAR |
| 10. | VI8941104800 | [1] | PLATE, THRUST | |
| 11. | VI9019108160 | [2] | BOLT | |
| 12. | VI8941293230 | [1] | SHAFT, IDLE GEAR, A | |
| 12-1. | VI8941701170 | [1] | SHAFT, IDLE GEAR, A | |
| 12-2. | VI8941397581 | [1] | LOCKING RING | KOBSHAFT, IDLE GEAR, A |
| 13. | VI8944020040 | [1] | GEAR, W/ BUSH, A | |
| 13-1. | VI8941397590 | [1] | GEAR, W/ BUSH, A | |
| 14. | VI5125350050 | [1] | COLLAR, THRUST | |
| 14-1. | VI8941419370 | [1] | COLLAR, THRUST | |
| 14-2. | VI8941712890 | [1] | COLLAR, THRUST | |
| 15. | VI5095030820 | [2] | WASHER, THRUST | |
| 16. | VI9010658650 | [2] | BOLT, IDLE SHAFT | |
| 16-1. | VI5090000840 | [2] | SCREW | KOBBOLT, IDLE SHAFT |
| 16-2. | VI9010658600 | [2] | BOLT, IDLE SHAFT | |
| 17. | VI9091508080 | [2] | WASHER, SPR. | |
| 18. | VI8941293260 | [1] | SHAFT, IDLE GEAR, B | |
| 18-1. | VI8941099130 | [1] | SHAFT, IDLE GEAR, B | |
| 20. | VI8941293240 | [1] | GEAR, W/ BUSH, B | |
| 20-1. | VI8941701180 | [1] | GEAR, W/ BUSH, B | |
| 20-2. | VI8941397610 | [1] | GEAR, W/ BUSH, B | |
| 21. | VI8941293840 | [1] | BOLT, SHAFT | |
| 21-1. | VI8941097060 | [1] | BOLT, SHAFT | |
| 22. | VI8941293800 | [1] | WASHER, IDLE FIX. | |
| 22-1. | VI5125190021 | [1] | WASHER | KOBWASHER, IDLE FIX. |
| 25. | VI8941332751 | [4] | VALVE | KOBVALVE, INLET Superseded by part number: VI8941332752 |
| 25-1. | VI8941712910 | [4] | VALVE, INLET | |
| 26. | VI8942478751 | [4] | VALVE, EXHAUST, OVER | KOBVALVE, EXH. Superseded by part number: VI8942478752 |
| 26-1. | VI8941712920 | [4] | VALVE, EXH. | |
| 27. | VI8942525361 | [8] | SPRING | KOBSPRING, VALVE, OUTER |
| 28. | VI8941337311 | [8] | SPRING | KOBSPRING SEAT, VALVE |
| 30. | VI5125650040 | [16] | COLLAR | KOBCOLLAR, SPLIT |
| 31. | VI8941335203 | [8] | TAPPET | |
| 32. | VI8941432020 | [8] | ROD | KOBROD, PUSH Superseded by part number: VI8970716730 |
| 32-1. | VI8941432030 | [8] | ROD, PUSH | |
| 33. | VI8941523440 | [8] | ROCKER ARM | KOBROCKER ARM. |
| 34. | VI8941522830 | [8] | SCREW | KOBADJ. Superseded by part number: VI8941522831 |
| 35. | VI9091115080 | [8] | NUT | KOBNUT Superseded by part number: VI0911115080 |
| 36. | VI8941523460 | [1] | ROCKER ARM | KOBSHAFT, ROCKER ARM Superseded by part number: VI8970361970 |
| 37. | VI9126260050 | [2] | PLUG | KOBPLUG, END |
| 38. | VI8941523450 | [4] | BRKT., ROCKER SHAFT | |
| 39. | VI8941007280 | [3] | SPRING, CMPR. | |
| 40. | VI9091800190 | [2] | SNAP RING | KOBSNAP RING |
| 41. | VI8941339722 | [3] | BOLT, ROCKER ARM | |
| 42. | VI9096511160 | [4] | WASHER | KOBWASHER, PLAIN |
| 43. | VI9010660600 | [1] | BOLT, ROCKER ARM | |
