神钢零件查询(4JB1) - ISUZU DIESEL ENGINE - K903C EXCAVATOR (1/06-12/07) (01-009) - OIL FILTER & FUEL FILTER ( FIXING PARTS) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
845 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VI8941337411 | [1] | FILTER ASM., OIL | |
| 1-1. | VI8944205290 | [1] | FILTER ASM., OIL | |
| 2. | VI8941678810 | [1] | BODY ASM., OIL FILTER | |
| 3. | VI8941678820 | [1] | VALVE ASM. | |
| 4. | VI8941678830 | [1] | PLUG | |
| 5. | VI8941678840 | [1] | O-RING | KOBO-RING |
| 6. | VI8941678850 | [1] | O-RING | KOBO-RING |
| 7. | VI8941678860 | [1] | GASKET | KOBO-RING |
| 8. | VI8941673990 | [1] | CARTRIDGE | |
| 10. | VI9132190570 | [1] | O-RING | KOBPACKING, OIL FILTER |
| 12. | VI9019708300 | [4] | SPECIAL BOLT | KOBBOLT, OIL FILTER Superseded by part number: VI0506408300 |
| 20. | VI8941434771 | [1] | FILTER ASSY | KOBFILTER ASM., FUEL Superseded by part number: VI8971798541 |
| 22. | VI5132120750 | [1] | COVER, FUEL FILTER | |
| 23. | VI9132600561 | [1] | VALVE | KOBASM., OVER FLOW Superseded by part number: VI9132600562 |
| 24. | VI9095720140 | [2] | PACKING | KOBPACKING |
| 25. | VI8941434790 | [1] | ELEMENT | KOBCARTRIDGE ASM. Superseded by part number: EN02P00001-2 |
| 26. | VI9092023080 | [1] | SCREW | KOBPLUG, OVER FLOW VALVE |
| 27. | VI9095714080 | [1] | PACKING | KOBPACKING Superseded by part number: 289808A1 |
| 28. | VI8944101920 | [1] | BRACKET, FUEL FILTER | |
| 28-1. | VI8944296700 | [1] | BRACKET, FUEL FILTER | |
| 28-2. | VI8944104040 | [1] | BRACKET | KOBBRACKET, FUEL FILTER |
| 29. | VI9044110200 | [2] | STUD, BRKT. | |
| 30. | VI9019110320 | [2] | BOLT | KOBFILTER Superseded by part number: VI0505410400 |
| 50. | VI8941746470 | [1] | FILTER & COOLER ASM., OIL | |
| 50-1. | VI8941754690 | [1] | FILTER & COOLER ASM., OIL | |
| 55. | VI8944016780 | [1] | BODY ASM. | |
| 57. | VI9000970110 | [1] | BALL, STEEL | |
| 58. | VI8944016790 | [1] | SPRING | |
| 59. | VI8941678820 | [1] | VALVE ASM. | |
| 60. | VI8941678830 | [1] | PLUG | |
| 61. | VI8941678840 | [1] | O-RING | KOBO-RING |
| 62. | VI8941678850 | [1] | O-RING | KOBO-RING |
| 63. | VI8941678860 | [1] | GASKET | KOBO-RING |
| 64. | VI8944016800 | [1] | COOLER ASM., OIL | |
| 65. | VI8941673990 | [1] | CARTRIDGE ASM. | |
| 65-1. | VI8944289310 | [1] | ELEMENT | KOBCARTRIDGE ASM. Superseded by part number: 2451U303-1 |
