| 1. | VI8941293320 | [1] | PUMP ASM., WATER | |
| 1-1. | VI8944237530 | [1] | WATER PUMP | KOBPUMP ASM., WATER Superseded by part number: VI8944237531 |
| 1-2. | VI8941701250 | [1] | PUMP ASM., WATER | |
| 2. | VI5878103810 | [1] | REPAIR KIT, WATER PUMP | |
| 2-1. | VI5878103820 | [1] | KIT, ENGINE TOP GASK | KOBREPAIR KIT, WATER PUMP Superseded by part number: VI5878156590 |
| 2-2. | VI5878103830 | [1] | REPAIR KIT, WATER PUMP | |
| 5. | VI8941303190 | [1] | COVER | |
| 5-1. | VI8941701270 | [1] | COVER | |
| 6. | VI8941303200 | [1] | PACKING | |
| 6-1. | VI8941701280 | [1] | PACKING | |
| 7. | VI5136210130 | [1] | IMPELLER | |
| 7-1. | VI8941147270 | [1] | IMPELLER | |
| 7-2. | VI8942501630 | [1] | IMPELLER | |
| 8. | VI8941105600 | [1] | BEARING | KOBUNIT, BRG. Superseded by part number: VI8944219420 |
| 10. | VI8942260080 | [1] | SEAL UNIT | |
| 11. | VI5136420640 | [1] | CENTER | |
| 12. | VI9136390010 | [1] | THROWER | |
| 13. | VI8941116150 | [1] | JOINT | |
| 14. | VI9098140141 | [1] | SCREW,SET | |
| 15. | VI9091505080 | [1] | WASHER | KOBWASHER, SPR. Superseded by part number: VI0915105080 |
| 16. | VI9030658160 | [3] | SCREW. | |
| 16-1. | VI9030658180 | [3] | SCREW | |
| 17. | VI9092045170 | [1] | PLUG | |
| 18. | VI8941293330 | [1] | PACKING, PUMP TO F. PLATE | |
| 18-1. | VI8944224290 | [1] | GASKET | KOBPACKING, PUMP TO F. PLATE Superseded by part number: VI8970955120 |
| 18-2. | VI8941780810 | [1] | GASKET | KOBPACKING, PUMP TO F. PLATE Superseded by part number: VI8941780811 |
| 19. | VI5090300370 | [5] | BOLT, SEMS PUMP, L=50 | |
| 20. | VI5090002280 | [2] | BOLT, SEMS PUMP, L=78 | |
| 20-1. | VI5090000840 | [2] | SCREW | KOBBOLT, SEMS PUMP, L=55 |
| 20-2. | VI9019108400 | [1] | BOLT, SEMS PUMP, L=40 | |
| 20-3. | VI5090000840 | [5] | SCREW | KOBBOLT, SEMS PUMP, L=55 |
| 21. | VI9041108220 | [2] | STUD | KOBSTUD, WATER PUMP |
| 22. | VI8942248290 | [2] | NUT | KOBNUT |
| 22-1. | VI9091104080 | [3] | HANGER | KOBNUT Superseded by part number: VI0911105080 |
| 23. | VI9091505080 | [3] | WASHER | KOBWASHER, SPR. Superseded by part number: VI0915105080 |
| 25. | VI9137130780 | [1] | OUTLET PIPE, WATER | |
| 25-1. | VI8942546011 | [1] | PIPE | KOBOUTLET PIPE, WATER |
| 25-2. | VI8941525950 | [1] | RIGID TUBE | KOBOUTLET PIPE, WATER Superseded by part number: VI8943685890 |
| 25-3. | VI9137130380 | [1] | RIGID TUBE | KOBOUTLET PIPE, WATER Superseded by part number: VI8971690151 |
| 26. | VI5096370130 | [1] | GASKET | KOBPACKING, OUTLET PIPE Superseded by part number: 355244A1 |
| 28. | VI9019708300 | [2] | SPECIAL BOLT | KOBBOLT, SEMS, OUTLET PIPE Superseded by part number: VI0506408300 |
| 29. | VI8942149620 | [1] | THERMOSTAT | KOB Superseded by part number: VI8970898910 |
| 30. | VI8941293340 | [1] | HOUSING ASM.,THERMOSTAT | |
| 30-1. | VI8941258531 | [1] | HOUSING ASM.,THERMOSTAT | |
| 30-2. | VI8941701291 | [1] | HOUSING ASM.,THERMOSTAT | |
| 30-3. | VI8944288120 | [1] | HOUSING | KOBHOUSING ASM., THERMOSTAT |
| 31. | VI5096050050 | [1] | PLUG | KOBPLUG, OUTLET PIPE |
| 31-1. | VI9096610050 | [1] | PLUG | KOBPLUG, THERMOMETER |
| 32. | VI8941293730 | [1] | HOSE, RUBBER, BY PASS | |
| 32-1. | VI8941097651 | [1] | HOSE, RUBBER, BY PASS | |
| 32-2. | VI8941096811 | [1] | HOSE | KOBHOSE, RUBBER, BY PASS Superseded by part number: 8941096811 |
| 32-3. | VI8941701400 | [1] | HOSE, RUBBER, BY PASS | |
| 33. | VI9099156441 | [2] | CLIP, BY PASS | |
| 33-1. | VI9097150531 | [2] | CLIP | KOBCLIP, BY PASS |
| 34. | VI8942582360 | [1] | GASKET | KOBPACKING, HOUSING Superseded by part number: VI8972161560 |
| 34-1. | VI8941712940 | [1] | GASKET | KOBPACKING, HOUSING Superseded by part number: VI8970908790 |
| 35. | VI9019108350 | [3] | BOLT, SEMS, HOUSING | |
| 35-1. | VI9019108450 | [2] | BOLT, SEMS, HOUSING | |
| 35-2. | VI9019108300 | [3] | COVER | KOBBOLT, SEMS, HOUSING Superseded by part number: VI0505408300 |
| 35-3. | VI9019108350 | [2] | BOLT, SEMS, HOUSING | |
| 35-4. | VI5090300200 | [2] | BOLT | KOBSEMS, HOUSING Superseded by part number: VI0280508700 |
| 36. | VI8941293780 | [1] | PULLEY, COOLING | |
| 36-1. | VI8941493590 | [1] | PULLEY, COOLING | |
| 36-2. | VI8944273600 | [1] | PULLEY, COOLING | |
| 36-3. | VI8944294280 | [1] | PULLEY, COOLING | |
| 36-4. | VI8941466380 | [1] | PULLEY, COOL ING | |
| 37. | VI9136420780 | [1] | SPACER | KOBSPACER, FAN T=32 |
| 38. | VI9136420761 | [1] | SPACER, FAN T=6 | |
| 38-1. | VI9136420790 | [1] | SPACER, FAN T=59.5 | |
| 38-2. | VI9891364230 | [1] | SPACER | KOBSPACER, FAN T=18 |
| 38-3. | VI9136420770 | [1] | SPACER, FAN T=26 | |
| 40. | VI5136603040 | [1] | FAN | KOBASM., D=400, 6 BLA0E Superseded by part number: VI5136603041 |
| 40-1. | VI8944080790 | [1] | FAN | KOBFAN ASM., D=380, 7 BLADE |
| 40-2. | VI5891366051 | [1] | FAN ASM., D=540, 7 BLADE | |
| 40-3. | VI5136603150 | [1] | FAN ASM., D=380, 6 BLADE | |
| 40-4. | VI8944350880 | [1] | FAN ASM., D=430, 6 BLADE | |
| 40-5. | VI5136602360 | [1] | FAN | KOBFAN ASM., D=475, 6 BLADE |
| 41. | VI8941493580 | [1] | PLATE, ADJ. | |
| 41-1. | VI8944237460 | [1] | STEEL PLATE | KOBPLATE, ADJ. |
| 41-2. | VI8944294290 | [1] | PLATE, ADJ. | |
| 41-3. | VI8944315610 | [1] | PLATE, ADJ. | |
| 42. | VI5090300370 | [2] | BOLT, SEMS ADJ. L=50 | |
| 42-1. | VI9019108220 | [1] | BOLT BOLT, SEMS ADJ. | BOLT BOLT, SEMS ADJ. |
| 42-2. | VI9019108300 | [1] | COVER | KOBBOLT, SEMS ADJ. Superseded by part number: VI0505408300 |
| 42-3. | VI9019108220 | [2] | BOLT BOLT, SEMS ADJ. | BOLT BOLT, SEMS ADJ. |
| 43. | VI5090300350 | [4] | BOLT, FAN TO PULLEY L=55 | |
| 43-1. | VI5090300370 | [4] | BOLT, FAN TO PULLEY | |
| 43-2. | VI5090300290 | [4] | BOLT, FAN TO PULLEY | |
| 43-3. | VI5090300430 | [4] | SPECIAL BOLT | KOBBOLT, FAN TO PULLEY Superseded by part number: VI0108058450 |
| 43-4. | VI5090001580 | [4] | BOLT, FAN TO PULLEY | |
| 43-5. | VI5090000840 | [4] | SCREW | KOBBOLT, FAN TO PULLEY |
| 43-6. | VI9010656650 | [4] | BOLT, FAN TO PULLEY | |
| 45. | VI8941537210 | [1] | BELT, COOLING B=1151 | |
| 45-1. | VI8942568000 | [1] | SPARE PART | HITBELT, COOLING Superseded by part number: VI8944791010 |
| 45-2. | VI1136710110 | [1] | BELT, COOLING | |
| 46. | VI9091105080 | [2] | HANGER | KOBNUT, OUTLET PIPE Superseded by part number: VI0911105080 |
| 47. | VI9091505080 | [2] | WASHER | KOBWASHER, SPR. Superseded by part number: VI0915105080 |
| 48. | VI9095713160 | [1] | O-RING | KOBPACKING, PLUG Superseded by part number: 355245A1 |
| 49. | VI8941337443 | [1] | PIPE, INLET, WATER | |
| 49-1. | VI8944294270 | [1] | PIPE, INLET, WATER | |
| 49-2. | VI8941746440 | [1] | PIPE, INLET, WATER | |
| 49-3. | VI8944340710 | [1] | PIPE, INLET, WATER | |
| 49-4. | VI8944358780 | [1] | PIPE, INLET, WATER | |
| 50. | VI8941718980 | [1] | O-RING | KOBPACKING, INLET PIPE |
| 51. | VI9019108220 | [2] | BOLT BOLT, INLET PIPE | BOLT BOLT, INLET PIPE |
