HK50592
|
[1] |
TOOL
|
ATT
SPARE PART KIT electric threader, complete, ordered thru wholegoods only
|
| 1. |
700710553
|
[1] |
HARNESS
|
CAS
wire
|
| 2. |
700710551
|
[1] |
HARNESS
|
CAS
wire
|
| 3. |
700122490
|
[1] |
BRACKET
|
HFI
switch
|
| 4. |
223-31
|
[1] |
FUSE,10 Amp, Type 3AG
|
CAS
30 amp. Superseded by part number: 86600094
|
| 5. |
306132C1
|
[4] |
CABLE TIE,14.5" L
|
IH
CABLE STRAP TIE nylon Superseded by part number: 435437A1
|
| 6. |
700125974
|
[1] |
ARM
|
HFI
WA actuator
|
| 7. |
413-424
|
[1] |
BOLT,Hex, 1/4" - 20 x 1-1/2", Gr 5
|
CAS
Superseded by part number: 72187192, 280112
|
| 8. |
232-4114
|
[1] |
LOCK NUT,1/4"-20, GC
|
CAS
hex top, 1/4"-20, GR/B Superseded by part number: 280129
|
| 9. |
433-512
|
[2] |
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 5
|
CAS
Superseded by part number: 280327
|
| 10. |
492-11031
|
[2] |
LOCK WASHER,5/16"
|
CAS
Superseded by part number: 83990583
|
| 11. |
425-105
|
[2] |
NUT,5/16"-18, G5
|
CAS
Superseded by part number: 9635082, 72187221
|
| 12. |
700126726
|
[1] |
PLATE
|
HFI
|
| 13. |
432-1016
|
[1] |
COTTER PIN,5/32" x 1"
|
CAS
5/32" x 1" Superseded by part number: 83903970
|
| 14. |
705541
|
[4] |
WASHER,0.53" ID x 1.06" OD x 0.14" Thk
|
CAS
hardened plain, 1/2"
|
| 15. |
700711353
|
[1] |
ACTUATOR
|
CAS
ASSY. electric, see Figure 09-16
|
| 16. |
722355
|
[2] |
CABLE
|
CAS
WIRE electrical
|
| 17. |
7723562
|
[1] |
ELECTRICAL WIRE
|
CAS
WIRE electrical
|
| 18. |
376852R91
|
[1] |
HOUSING
|
IH
HOLDER fuse Superseded by part number: 578489
|
| 19. |
7723372
|
[1] |
SWITCH
|
IH
|
| 20. |
413-876
|
[1] |
BOLT,Hex, 1/2" - 13 x 4-3/4", Gr 5
|
CAS
hex cap, 1/2"-13 x 4-3/4" Superseded by part number: 280376
|
| 21. |
230-4118
|
[1] |
LOCK NUT,1/2"-13, GA
|
CAS
lock, hex top, 1/2"-13, GR/B
|
| 22. |
700125977
|
[1] |
ANGLE
|
HFI
actuator support
|
| 23. |
409-7612
|
[2] |
BOLT,3/8"-16 x 1.09" OAL
|
CAS
Superseded by part number: 72187187, 255918
|
| 24. |
231-5146
|
[2] |
FLANGE NUT,3/8"-16
|
CAS
Superseded by part number: 72187068, 247780
|
| 25. |
700710552
|
[1] |
HARNESS
|
CAS
wire
|
