凯斯零件查询(8420) - CASE IH ROUND BALER (1/88-12/00) (09-16) - ACTUATOR ASSEMBLY Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
301 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700711353
|
[1] |
ACTUATOR
|
CAS
ASSY. complete
|
| 2. |
700711355
|
[1] |
COVER
|
CAS
ASSY. tube
|
| 3. |
700711354
|
[1] |
SCREW
|
CAS
drive, ACME
|
| 4. |
700704854
|
[1] |
HOUSING
|
HFI
rear
|
| 5. |
700704873
|
[1] |
CLUTCH ASSEMBLY
|
HFI
|
| 6. |
91230C1
|
[1] |
GEAR
|
IH
ASSY. intermediate
|
| 7. |
700711356
|
[1] |
HOUSING
|
CAS
front
|
| 8. |
700711359
|
[1] |
MOTOR
|
CAS
ASSY.
|
| 9. |
1281489C1
|
[1] |
SEAL KIT
|
CAS
KIT repair, includes items marked with an asterisk on the illustration
|
