神钢零件查询(4D31-T) - MITSUBISHI DIESEL ENGINE (1/88-12/06) (01-014) - VALVE GEAR TRAIN Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
700 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VAME011263 | [4] | VALVE, INLET | |
| 2. | VAME011266 | [4] | VALVE | KOBVALVE, EXH Superseded by part number: VAME013832 |
| 3. | VAME029101 | [8] | VALVE SPRING | KOBSPRING, VALVE OUTER |
| 4. | VAME029102 | [8] | VALVE SPRING | KOBSPRING, VALVE INNER |
| 6. | VAME011268 | [8] | RETAINER | KOBRETAINER, UPPER |
| 7. | VAME024108 | [8] | STEM SEAL SEAL, VALVE STEM | STEM SEAL SEAL, VALVE STEM |
| 8. | VAME011227 | [16] | VALVE | KOBCOTTER, VALVE, AVAILABLE IN SET WITH PAIR |
| 10. | VAME020244 | [8] | CAP | KOBCAP, VALVE Superseded by part number: VAME017459 |
| 11-12. | VAME011292 | [8] | ROCKER | KOBROCKER ASSY |
| 11. | NSS | [8] | NOT SOLD SEPARAT | CONROCKER |
| 12. | VAME011254 | [8] | BUSHING | KOBBUSHING, ROCKER |
| 15. | VAMH001002 | [8] | SCREW | KOBSCREW, ADJUSTING 8 X 32 Superseded by part number: VAME220221 |
| 16. | VAMF430841 | [8] | NUT | KOBNUT 8 |
| 17-18. | VAME011274 | [1] | ROCKER SHAFT ASSY | |
| 17. | NSS | [1] | NOT SOLD SEPARAT | CONSHAFT, ROCKER |
| 18. | VAMF665532 | [2] | CAP, SEALING 12 | |
| 20. | VAME011257 | [1] | BRACKET | KOBRRACKET, ROCKER SHAFT, FR |
| 21. | VAME011258 | [2] | BRACKET | KOBRRACKET, ROCKER SHAFT, 2, 4, 6 |
| 21A. | VAME011259 | [1] | BRACKET | KOBRRACKET, ROCKER SHAFT, 3, 5 |
| 22. | VAME011260 | [1] | BRACKET | KOBRRACKET, ROCKER SHAFT, RE |
| 23. | VAMF140003 | [2] | BOLT | KOBBOLT, FLANGE 6 X 12 |
| 24. | VAME011261 | [4] | SPRING | KOBSPRING, ROCKER SHAFT |
| 25. | VAMH007012 | [2] | PIN | KOBPIN,SPG 17 X 10 |
| 30. | VAME011267 | [8] | PUSH ROD | KOBTAPPERT Superseded by part number: VAME012991 |
| 31. | VAME011267 | [8] | PUSH ROD | KOBPUSHROD Superseded by part number: VAME012991 |
