| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 5. |
VOE4739980
|
[0002] |
Flange
|
CH -1812
|
| 50. |
VOE11147586
|
[0002] |
Dust cover
|
|
| 51. |
VOE4929988
|
[0002] |
Clamp
|
SER NO 1203 -
|
| 52. |
VOE13970950
|
[0002] |
Hexagon screw
|
SER NO 1203-
|
| 53. |
VOE941908
|
[0002] |
Spring washer
|
SER NO 1203-
|
| 6. |
VOE4780711
|
[0002] |
Hollow screw
|
CH -1812
|
| 7. |
VOE949659
|
[0002] |
O-ring
|
|
| 8. |
VOE14013071
|
[0002] |
Sealing washer
|
CH -1812
|
| 9. |
VOE930399
|
[0008] |
Screw
|
|
| 1. |
|
[0001] |
Control valve
|
|
| 10. |
VOE13941907
|
[0008] |
Washer
|
SER NO -2586
|
| 11. |
VOE4739984
|
[0002] |
Clamp
|
SER NO -2631
|
| |
VOE4929988
|
[0001] |
Clamp
|
SER NO 2632-
|
| 12. |
VOE13955894
|
[0004] |
Washer
|
SER NO -2631
|
| |
VOE13955894
|
[0002] |
Washer
|
SER NO 2632-
|
| 13. |
VOE963106
|
[0004] |
Lock nut
|
SER NO -2631
|
| |
VOE955782
|
[0001] |
Hexagon nut
|
SER NO 2632-
|
| |
VOE60111880
|
[0001] |
Hexagon screw
|
SER NO 2632-
|
| 14. |
VOE931711
|
[0002] |
Hose assembly
|
SER NO -3207
|
| |
VOE4880494
|
[0002] |
O-ring
|
|
| |
VOE931890
|
[0002] |
Hose assembly
|
SER NO 3208-
|
| |
VOE958228
|
[0002] |
O-ring
|
SER NO 3208-
|
| |
VOE4880494
|
[0002] |
O-ring
|
|
| 15. |
|
[0002] |
Hose
|
|
| 16. |
VOE4741576
|
[0001] |
Anchorage
|
|
| 17. |
VOE970945
|
[0003] |
Hexagon screw
|
|
| 18. |
VOE941908
|
[0003] |
Spring washer
|
|
| 19. |
VOE976945
|
[0003] |
Washer
|
|
| 2. |
VOE4927543
|
[0001] |
Feed line
|
SER NO -1812
|
| 20. |
VOE4763566
|
[0002] |
Clamp
|
|
| |
VOE4929336
|
[0001] |
Tube
|
SER NO 1813 - 3207
|
| |
VOE4932592
|
[0001] |
Tube
|
SER NO 3208-
|
| 21. |
VOE13955894
|
[0004] |
Washer
|
|
| 22. |
VOE963106
|
[0004] |
Lock nut
|
|
| 23. |
VOE4743543
|
[0001] |
Protection
|
|
| 24. |
VOE4854405
|
[0002] |
Elbow
|
|
| 25. |
VOE13943988
|
[0004] |
Nipple
|
|
| 26. |
VOE14013070
|
[0004] |
Sealing washer
|
|
| 27. |
VOE4949210
|
[0001] |
Pipe
|
|
| 28. |
VOE4949212
|
[0001] |
Pipe
|
|
| 29. |
VOE4763516
|
[0001] |
Anchorage
|
SER NO -1352
|
| 3. |
VOE4927537
|
[0001] |
Feed line
|
SER NO -1812
|
| 30. |
VOE4763517
|
[0001] |
Anchorage
|
SER NO -1352
|
| |
VOE4929334
|
[0001] |
Tube
|
SER NO 1813 - 3207
|
| |
VOE4932591
|
[0001] |
Tube
|
SER NO 3208-
|
| 31. |
VOE970945
|
[0004] |
Hexagon screw
|
SER NO -1352
|
| 32. |
VOE941908
|
[0004] |
Spring washer
|
SER NO -1352
|
| 33. |
VOE976945
|
[0004] |
Washer
|
SER NO -1352
|
| 34. |
VOE4739984
|
[0002] |
Clamp
|
|
| 35. |
VOE13955894
|
[0004] |
Washer
|
|
| 36. |
VOE963106
|
[0004] |
Lock nut
|
|
| 37. |
VOE931707
|
[0002] |
Hose assembly
|
|
| |
VOE4880494
|
[0004] |
O-ring
|
|
| 38. |
VOE957060
|
[0002] |
Nipple
|
SER NO -1352
|
| |
VOE957060
|
[0004] |
Nipple
|
SER NO 1353-
|
| 39. |
VOE11002293
|
[0002] |
Tube
|
|
| 4. |
VOE4780734
|
[0002] |
Back-up ring
|
|
| 40. |
VOE4763679
|
[0002] |
Bracket
|
|
| 40A. |
VOE4928942
|
[0002] |
Spacer
|
SER NO 1353-
|
| 41. |
VOE4763716
|
[0002] |
Bracket
|
|
| 42. |
VOE970945
|
[0008] |
Hexagon screw
|
|
| 43. |
VOE941908
|
[0008] |
Spring washer
|
|
| 44. |
VOE976945
|
[0008] |
Washer
|
|
| 45. |
VOE4739984
|
[0004] |
Clamp
|
|
| 46. |
VOE13955894
|
[0008] |
Washer
|
|
| 47. |
VOE963106
|
[0008] |
Lock nut
|
|
| 48. |
VOE11043022
|
[0002] |
Nipple
|
|
| 49. |
VOE14013070
|
[0002] |
Sealing washer
|
|
