凯斯零件查询(8420) - CASE IH ROUND BALER (1/88-12/00) (07-06) - WHEEL SUPPORT MAINFRAME ASSEMBLY Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
238 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
T52730
|
[10] |
WHEEL BOLT
|
IH
wheel, 9/16"-18 x 1-1/8" Superseded by part number: 86628557
|
| 2. |
413-1028
|
[8] |
BOLT,Hex, 5/8" - 11 x 1-3/4", Gr 5
|
CAS
SCREW hex cap, 5/8"-11 x 1-3/4" Superseded by part number: 9627896
|
| 3. |
492-11062
|
[8] |
BEARING WASHER,5/8"
|
CAS
Superseded by part number: 86729275
|
| 4. |
425-1010
|
[8] |
NUT,5/8"-11, G5
|
CAS
Superseded by part number: 280374
|
| 5. |
6280770
|
[2] |
HUB
|
HFI
ASSY., see Figure 07-20
|
| 6. |
700100009
|
[2] |
PIN
|
CAS
WA handle
|
