| 1-25. | VAME019911 | [1] | STARTER MOTOR | KOBSTARTER ASSY 24V-5KW, MEC M003157575 Superseded by part number: VAME049186 |
| 1. | VAME700050 | [1] | SCREW SCREW SET, MEC M414X051/1 | SCREW SCREW SET, MEC M414X051/1 |
| 3. | VAME700233 | [1] | BRACKET ASSY BRACKET ASSY FR, MEC M641X637/1 | BRACKET ASSY BRACKET ASSY FR, MEC M641X637/1 |
| 4. | VAME700234 | [1] | LEVER | KOBLEVER ASSY, MEC M863C056/2 Superseded by part number: VAM863C05672 |
| 5. | VAME700033 | [1] | PACKING PACKING, MEC M576020501 | PACKING PACKING, MEC M576020501 |
| 6. | VAME700235 | [1] | BRACKET | KOBBRACKET ASSY CTR, MEC M640B26971 |
| 7. | VAME700236 | [1] | SWITCH ASSY SWITCH ASSY, MEC M371X206/2 | SWITCH ASSY SWITCH ASSY, MEC M371X206/2 |
| 9-11. | VAME700037 | [1] | ARMATURE | KOBARMATURE ASSY, MEC M106X29171 Superseded by part number: VAM106X29171 |
| 9. | NSS | [1] | NOT SOLD SEPARAT | CONARMATURE |
| 10. | VAME700038 | [1] | BEARING | KOBBEARING, MEC 5930P12370 Superseded by part number: 135040A1 |
| 11. | VAME700099 | [1] | BEARING, MEC 5930P60570 | |
| 12. | VAME700036 | [1] | BOLT | KOBBOLT SET, MEC M901X01771 Superseded by part number: VAM901X01771 |
| 14-18. | VAME700237 | [1] | EXCHANGE CLUTCH ASSY | KOBCLUTCH SET SHAFT ASSY |
| 14-15. | VAME700239 | [1] | SET OF PINIONS | KOBPINION SET, MEC M357X03/76 |
| 14. | NSS | [1] | NOT SOLD SEPARAT | CONPINION, MEC M605Y276/1 |
| 15. | VAME700124 | [1] | STOP | KOBSTOPPER SET, MEC M385X06771 Superseded by part number: VAM385X03771 |
| 16-17. | VAME700238 | [1] | GEAR SET, MEC M231X00677 | |
| 16. | VAME700043 | [1] | DRIVEN GEAR | KOBGEAR, MEC M231C00601 |
| 17. | VAME700121 | [1] | SHAFT | KOBPINION SHAFT ASSY, MEC M357C71671 |
| 18. | VAME700045 | [1] | COVER SET COVER SET, MEC M212X11571 | COVER SET COVER SET, MEC M212X11571 |
| 20. | VAME700049 | [2] | PACKING PACKING, MEC M570D14501 | PACKING PACKING, MEC M570D14501 |
| 21. | VAME700240 | [1] | YOLK ASSY YOKE ASSY, MEC M800X44274 | YOLK ASSY YOKE ASSY, MEC M800X44274 |
| 22-23. | VAME700047 | [1] | HOLDER BRUSH HOLDER ASSY, MEC M649T04971 | HOLDER BRUSH HOLDER ASSY, MEC M649T04971 |
| 22. | NSS | [1] | NOT SOLD SEPARAT | CONHOLDER, BRUSH |
| 23. | VAMD607462 | [4] | SPRING SPRING, BRUSH, MEC M391C02201 | SPRING SPRING, BRUSH, MEC M391C02201 |
| 24. | VAME700048 | [1] | U-BRACKET | KOBBRACKET, RE, MEC M644B20701 Superseded by part number: 135050A1 |
| 25. | VAME700026 | [2] | SEAL RETAINER | KOBRING, RUBBER Superseded by part number: 135064A1 |
