神钢零件查询(4D31-T) - MITSUBISHI DIESEL ENGINE (1/88-12/06) (03-005) - FUEL INJECTION PIPE Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
704 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VAME019621 | [1] | INJECTION PIPE | KOBPIPE, INJECTION NO. 1 |
| 2. | VAME019622 | [1] | INJECTION PIPE | KOBPIPE, INJECTION NO. 2 |
| 3. | VAME080161 | [1] | INJECTION PIPE | KOBPIPE, INJECTION NO. 3 |
| 4. | VAME080162 | [1] | PIPE | KOBPIPE, INJECTION NO. 4 |
| . . | VA3176109100 | [1] | PIPE INJECTION PIPE, INJECTION STRAIGHT L=590 | PIPE INJECTION PIPE, INJECTION STRAIGHT L=590 |
| 6. | VAMH021250 | [4] | CLAMP | KOBCLAMP A |
| 7. | VAMF434103 | [2] | NUT | KOBNUT, FLANGE 6 |
| 9. | VAMH020258 | [2] | CLAMP | KOBCLAMP Superseded by part number: 134717A1 |
| 10. | VAMH020259 | [2] | CLAMP | KOBCLAMP Superseded by part number: 134718A1 |
| 11. | VAMF140207 | [2] | SHOCK ABSORBER BOLT, FLANGE 6 X 20 | SHOCK ABSORBER BOLT, FLANGE 6 X 20 |
