凯斯零件查询(8430) - CASE IH ROUND BALER (1/88-12/00) (2-12) - DRIVE ASSEMBLY (PRIMARY), (S.N.CFH0012765 AND LATER) Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
831 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
195-2139
|
[3] |
WASHER,36.52mm ID x 57.15mm OD x 2.03mm Thk
|
IH
1-3/8 x 14 GA. NRMB
|
| 2. |
52266
|
[2] |
WASHER
|
CAS
1-1/4 x 14 GA. NRMB Superseded by part number: 495-81205
|
| 3. |
495-81205
|
[3] |
WASHER,32.54mm ID x 50.8mm OD x 1.7mm Thk
|
CAS
1-1/4 x 18 GA. NRMB
|
| 4. |
761197
|
[1] |
WOODRUFF KEY,#23, 5/16" x 1 3/8"
|
CAS
Superseded by part number: 126-36
|
| 5. |
700126741
|
[1] |
SHAFT
|
HFI
ASSEMBLY
|
| 6. |
700708091
|
[1] |
SPHERICAL BEARING,34.93 mm ID x 72 mm OD x 38.89 mm
|
CAS
BEARING - spherical Superseded by part number: 47577188, 47066
|
| 7. |
825620C1
|
[2] |
RETAINER
|
IH
- bearing
|
| 8. |
700120435
|
[1] |
SUPPORT
|
HFI
- bearing Superseded by part number: 700131801
|
| 9. |
61101
|
[1] |
KEY
|
HFI
1/4 x 1/4 x 1-3/4 KEY
|
| 10. |
700712602
|
[1] |
GEARBOX ASSY
|
L
GEARBOX ASSEMBLY Superseded by part number: 700725501
|
| . . |
703959
|
[4] |
BOLT,Hex, 1/2" - 13 x 1", Gr 5, Full Thd
|
CAS
1/2-13 x 1 C
|
| . . |
7702038
|
[1] |
SCREW,Hex, 1/2" - 13 x 3", Gr 5
|
CAS
1/2-13 x 3 C Superseded by part number: 87339
|
| . . |
700047
|
[3] |
BOLT
|
CAS
3/8-16 x 1 RHSNB Superseded by part number: 80280503
|
| . . |
7771363
|
[4] |
BOLT,Hex Flange, 1/2" - 13 x 1 1/4", SPL
|
CAS
1/2-13 x 1-1/4 HFSS Superseded by part number: 84209
|
| . . |
704031
|
[5] |
NUT
|
NNA
1/2-13 H Superseded by part number: 425-108, 425-108, NLS
|
| . . |
80679
|
[5] |
LOCK WASHER,1/20.507 CST ZND
|
NH
WASHER, LOCK, 1/2"
|
