凯斯零件查询(8430) - CASE IH ROUND BALER (1/88-12/00) (2-26) - DRIVE ASSEMBLY (LOWER ROLLERS) Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
521 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
80702
|
[4] |
WASHER,0.44" ID x 1" OD x 0.08" Thk
|
NH
3/8 HARDENED PLAIN WASHER
|
| 2. |
7053523
|
[2] |
HALF-ROLLER
|
L
SHEAVE - half
|
| 3. |
6867717
|
[3] |
SHIM
|
CAS
|
| 4. |
700120941
|
[1] |
SPROCKET ASSY.
|
HFI
SPROCKET - double, 14 tooth, with flange
|
| 5. |
761353
|
[1] |
KEY
|
CAS
3/8 x 3/8 x 3-1/2 GIB KEY
|
| 6. |
705582
|
[1] |
WASHER
|
CAS
5/8 HARDENED PLAIN WASHER Superseded by part number: 396-21066, 396-21066, NLS
|
| 7. |
700120934
|
[1] |
SUPPORT
|
HFI
- idler, sprocket
|
| 8. |
700120928
|
[1] |
SPROCKET ASSY.
|
HFI
SPROCKET - 16 tooth
|
| 9. |
61432
|
[2] |
BUCKET TOOTH KEY
|
IH
3/8 x 3/8 x 1-1/2 GIB KEY
|
| 10. |
700120938
|
[1] |
SPROCKET ASSY.
|
HFI
SPROCKET - double, 24 and 36 tooth
|
| 11. |
541857R92
|
[1] |
SPROCKET,15T
|
IH
- idler, 15 tooth
|
| . . |
703249
|
[4] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 x 1 C Superseded by part number: 88206
|
| . . |
703934
|
[1] |
BOLT,Hex, 5/8" - 11 x 5 1/2", Gr 5
|
CAS
5/8-11 x 5-1/2 C Superseded by part number: 280232, 280232, 87791065
|
| . . |
704130
|
[1] |
NUT,5/8"-11, G5
|
CAS
5/8-11 H Superseded by part number: 280374
|
| . . |
705038
|
[4] |
CONTROL VALVE
|
CAS
3/8" Superseded by part number: 492-11038
|
| . . |
705051
|
[1] |
5/8 L
|
CONNECTING LINK
|
