凯斯零件查询(8430) - CASE IH ROUND BALER (1/88-12/00) (3-02) - DEFLECTOR AND PICKUP CONTROL ASSEMBLY Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
1019 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700117140
|
[1] |
MOUNTING PARTS
|
HFI
MOUNTING - lever
|
| 2. |
6255350
|
[4] |
SPACER
|
CAS
|
| 3. |
451526
|
[5] |
THRUST WASHER
|
CAS
|
| 4. |
427-6106
|
[1] |
CLEVIS PIN,9.53mm OD x 26.92mm L
|
CAS
3/8 x 1 CLEVIS PIN Superseded by part number: 510390
|
| 5. |
700120540
|
[1] |
LEVER
|
HFI
|
| 6. |
S120261
|
[1] |
PIN
|
CAS
HAIRPIN COTTER
|
| 7. |
6264998
|
[1] |
SPACER
|
CAS
|
| 8. |
700117269
|
[1] |
STRAP
|
HFI
|
| 9. |
700120521
|
[1] |
SEPARATOR
|
HFI
WA
|
| 10. |
700120539
|
[2] |
STRAP
|
HFI
- lift
|
| 11. |
700120533
|
[1] |
DEFLECTOR
|
HFI
WA - right Superseded by part number: 700131765
|
| 12. |
700120532
|
[1] |
DEFLECTOR
|
HFI
WA - left Superseded by part number: 700131764
|
| . . |
702035
|
[1] |
BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 5, Full Thd
|
CAS
3/8-16 x 1-1/4 C
|
| . . |
703603
|
[1] |
SCREW
|
CAS
3/8-16 x 1-1/2 C
|
| . . |
7701634
|
[1] |
BOLT,Hex, 3/8" - 16 x 2", Gr 5
|
CAS
3/8-16 x 2 C Superseded by part number: 88436
|
| . . |
702928
|
[1] |
BOLT,Hex, 3/8" - 16 x 2 3/4", Gr 5
|
CAS
3/8-16 x 2-3/4 C
|
| . . |
700047
|
[6] |
BOLT
|
CAS
3/8-16 x 1 RHSNB Superseded by part number: 80280503
|
| . . |
7703432
|
[3] |
BOLT,Hex, Serr, 3/8" - 16 x 3/4"
|
CAS
3/8-26 x 3/4 HFSS Superseded by part number: 255918
|
| . . |
7703424
|
[2] |
FLANGE BOLT,Hex, Serr, 3/8" - 16 x 1"
|
CAS
3/8-16 x 1 HFSS Superseded by part number: 9706726
|
| . . |
704023
|
[4] |
NUT,3/8"-16, G5
|
CAS
3/8-16 H Superseded by part number: 280136
|
| . . |
704247
|
[11] |
NUT
|
CAS
3/8-16 HFSLN Superseded by part number: 231-5146, 231-5146, 280736, 231-5146, 280736, 692965, 231-5146, 280736, 692965, 87362
|
| . . |
705038
|
[4] |
CONTROL VALVE
|
CAS
3/8" Superseded by part number: 492-11038
|
