凯斯零件查询(8430) - CASE IH ROUND BALER (1/88-12/00) (6-14) - DRIVE ROLLER ASSEMBLY (LOWER-METAL) Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
885 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
663562R1
|
[4] |
FLANGE
|
IH
- bearing
|
| 2. |
7852213
|
[12] |
SHIM
|
HFI
WASHER - shim
|
| 3. |
50468
|
[2] |
SPHERICAL BEARING,38.1 mm ID x 80 mm OD x 22, 43.66 mm
|
IH
- spherical
|
| 4. |
700120476
|
[2] |
SUPPORT
|
HFI
- bearing
|
| 5. |
700110467
|
[1] |
BEARING ASSY,44.45 mm ID x 92.44 mm OD x 29 mm
|
L
BEARING ASSEMBLY (includes item 6)
|
| 6. |
51318
|
[2] |
BEARING
|
IH
- spherical Superseded by part number: 668718R92, 47577169
|
| 7. |
50583
|
[2] |
FLANGED BEARING
|
IH
BEARING - spherical Superseded by part number: 86979948
|
| 8. |
700120467
|
[1] |
ROLLER
|
HFI
WA
|
| 9. |
700120471
|
[1] |
ROLLER
|
HFI
WA
|
| . . |
7700065
|
[5] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 3/4", Gr 5
|
CAS
3/8-16 x 3/4 RHSNB Superseded by part number: 280430
|
| . . |
700047
|
[3] |
BOLT
|
CAS
3/8-16 x 1 RHSNB Superseded by part number: 80280503
|
| . . |
7700131
|
[16] |
SHROUD,Sq Nk, 1/2" - 13 x 1", Gr 5
|
CAS
1/2-13 x 1 RHSNB Superseded by part number: 433-816, 433-816, NLS
|
| . . |
704247
|
[8] |
NUT
|
CAS
3/8-16 HFSLN Superseded by part number: 231-5146, 231-5146, 280736, 231-5146, 280736, 692965, 231-5146, 280736, 692965, 87362
|
| . . |
704254
|
[16] |
NUT,Flg, USR, 1/2"-13
|
CAS
1/2-13 HFSLN Superseded by part number: 86512371
|
