| 1. |
241-1315
|
[1] |
LINK, CONNECTING
|
CAS
LINK - connector, #50 Superseded by part number: 87034815
|
| 2. |
1791D
|
[1] |
CHAIN (AG),#50, 192 Links x 15.88mm = 3048mm
|
IH
CHAIN - roller, #50 (10 foot bulk)
|
| 3. |
121-433
|
[1] |
FLANGE BOLT,Hex, 1/2" - 13 x 2", Gr 8
|
CAS
1/2-13 X 2 HFS GR8
|
| 4. |
700716888
|
[1] |
SPROCKET ASSY.
|
CAS
IDLER - sprocket, 17 tooth
|
| 5. |
95-81100
|
[3] |
WASHER,33/64" x 7/8" x .049"
|
CAS
1/2 X 18 GAUGE NRMB Superseded by part number: 86639334
|
| 6. |
705541
|
[1] |
WASHER,0.53" ID x 1.06" OD x 0.14" Thk
|
CAS
1/2 HARDENED PLAIN WASHER
|
| 7. |
425-108
|
[2] |
NUT,1/2" - 13, Gr 5
|
CAS
NUT, , Hex 1/2"-13, G5 Superseded by part number: 280431
|
| 8. |
700147510
|
[1] |
SPECIAL BOLT
|
HFI
DRAWBOLT WA
|
| 9. |
700147566
|
[2] |
RETAINER
|
HFI
|
| 10. |
7845357
|
[2] |
WASHER
|
CAS
- spring
|
| 11. |
121-237
|
[2] |
SERRATED BOLT,Hex, 3/8" - 16 x 1 1/4, Spcl
|
CAS
3/8-16 X 1-1/4 HFS GR8 Superseded by part number: 87327172
|
| 12. |
232-5316
|
[16] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| 13. |
700132123
|
[1] |
GUARD
|
HFI
WINDGUARD WA Superseded by part number: 700153610
|
| 14. |
700147508
|
[1] |
SHIELD
|
HFI
WA - left
|
| 15. |
700147509
|
[1] |
SHIELD
|
HFI
- left
|
| 16. |
700132114
|
[1] |
SUPPORT
|
HFI
WRAPPER - end, left
|
| 17. |
700132112
|
[23] |
WRAPPER
|
HFI
- tine
|
| 18. |
121-115
|
[60] |
SERRATED BOLT,Hex, 5/16" - 18 x 3/4"
|
CAS
|
| 19. |
700132115
|
[1] |
SUPPORT
|
HFI
WRAPPER - end, right
|
| 20. |
700132122
|
[1] |
SHIELD
|
HFI
- right
|
| 21. |
700132117
|
[1] |
SHIELD
|
HFI
- right
|
| 22. |
121-226
|
[5] |
SERRATED BOLT,Hex, 3/8" - 16 x 1"
|
CAS
Superseded by part number: 87034804
|
| 23. |
496-11041
|
[3] |
WASHER,13/32" x 13/16" x .065", HDN
|
CAS
3/8 HARDENED PLAIN WASHER Superseded by part number: 86632588
|
| 24. |
700116125
|
[1] |
HOUSING
|
CAS
CAMTRACK
|
| 25. |
700132128
|
[4] |
SHIM
|
HFI
|
| 26. |
434-616
|
[9] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 X 1 RHSNB Superseded by part number: 80280503
|
| 27. |
413-620
|
[3] |
BOLT,Hex, 3/8" - 16 x 1-1/4", Gr 5
|
CAS
C Hex, 3/8"-16 x 1 1/4", G5, Full Thd Superseded by part number: 72187207, 88011
|
| 28. |
700135815
|
[1] |
FRAME
|
HFI
WA - pickup
|
| 29. |
700708091
|
[2] |
SPHERICAL BEARING,34.93 mm ID x 72 mm OD x 38.89 mm
|
CAS
BEARING - spherical Superseded by part number: 47577188, 47066
|
| 30. |
617863R1
|
[4] |
FLANGED BEARING
|
IH
|
| 31. |
Q3929
|
[1] |
KEY,Gib, 5/16" Sq x 1 1/2"
|
IH
5/16 X 1-1/2 GIB KEY
|
| 32. |
700132131
|
[1] |
SLINGER
|
HFI
- inner
|
| 33. |
700147513
|
[1] |
SPROCKET ASSY.
|
HFI
SPROCKET WA - 50B43 tooth
|
| 34. |
700147558
|
[1] |
ROTOR ASSY.
|
HFI
ROTOR ASSEMBLY
|
