| 1. |
700707665
|
[2] |
LARGE PLATE
|
IH
Leaf - Spring
|
| 2. |
700107980
|
[1] |
ARM
|
CAS
- Threader, Twine
|
| 3. |
700107985
|
[1] |
SHAFT
|
CAS
Jackshaft - Gear (S.N. CFH0015001 thru 0015274) Superseded by part number: 700118878, 700118879
|
| 3. |
700118878
|
[1] |
SHAFT
|
CAS
Jackshaft - Gear (S.N. CFH0015275 and on)
|
| 4. |
740159
|
[2] |
RING, SNAP
|
CAS
Ring - Retainer Superseded by part number: 25121
|
| 5. |
700107978
|
[1] |
PLATE
|
HFI
|
| 6. |
700107977
|
[2] |
GUIDE
|
CAS
- Twine
|
| 7. |
219-8
|
[2] |
LUBE NIPPLE,1/4" - 28 NPTF
|
CAS
NIPPLE, LUBE, 1/4"-28 NPT x .54" lg Superseded by part number: 87414
|
| 8. |
52266
|
[4] |
WASHER
|
CAS
1-1/4 x 14 Gauge Machinery Bushing Superseded by part number: 495-81205
|
| 9. |
52613
|
[2] |
RING, SNAP
|
CAS
Ring - Retainer Superseded by part number: 103-11125
|
| 10. |
6500540
|
[1] |
GEARBOX
|
CAS
Superseded by part number: 700709190
|
| 10. |
700709190
|
[1] |
GEARBOX ASSY
|
CAS
Gearbox
|
| 10. |
700710131
|
[1] |
TRANSFER BOX
|
IH
Gearbox (S.N. CFH0015897 and on) Superseded by part number: 700725114
|
| 11. |
7751605
|
[1] |
BREATHER
|
CAS
Vent - Breather Superseded by part number: 219-433
|
| 12. |
846642
|
[1] |
BUSHING
|
CAS
- Reducer
|
| 13. |
700107974
|
[1] |
INDICATOR
|
HFI
- Threader Arm
|
| 14. |
6549869
|
[2] |
SUPPORT
|
L
Bracket - Tension
|
| 15. |
700107969
|
[1] |
PLATE
|
HFI
Support - Pulley, Twine
|
| 16. |
6869382
|
[1] |
SPACER
|
HFI
|
| 17. |
700116222
|
[1] |
PULLEY ASSY.
|
HFI
Pulley - Feeder, Twine
|
| 18. |
700707677
|
[2] |
SPRING
|
L
- Compression
|
| 19. |
7745003
|
[1] |
GUIDE
|
L
- Twine
|
| 20. |
766543
|
[1] |
SCREW
|
L
5/16-18 Thread Superseded by part number: 51200861
|
| 21. |
7741119
|
[2] |
HOSE CLAMP
|
CAS
- Hose Superseded by part number: 214-1406, 214-1406, 70921910
|
| 22. |
700707201
|
[1] |
HOSE
|
CAS
- Flex
|
| 23. |
700707402
|
[1] |
BEARING, ROLLER, CYL,10 mm ID x 30 mm OD x 9 mm
|
CAS
Bearing - Cylindrical Superseded by part number: 9847562
|
| 24. |
740514
|
[2] |
BUSHING,31.81mm ID x 38.2mm OD x 50.8mm L
|
L
- Oilite
|
| 25. |
700707403
|
[1] |
RING
|
IH
- Retainer Superseded by part number: 129738
|
| 26. |
700118879
|
[1] |
NUT
|
CAS
- Special (S.N. CFH0015767 and on)
|
| 27. |
858183
|
[1] |
SPRING
|
CAS
- Compression (S.N. CFH0015767 and on)
|
| 28. |
700122575
|
[1] |
BUTTON
|
CAS
- Nylon
|
| 29. |
705517
|
[2] |
WASHER
|
CAS
1/4 Hardened Plain Washer Superseded by part number: 496-11028, 496-11028, 70900816
|
| 30. |
705525
|
[2] |
WASHER
|
CAS
5/16 Hardened Plain Washer Superseded by part number: 86637953
|
| 31. |
80702
|
[1] |
WASHER,0.44" ID x 1" OD x 0.08" Thk
|
NH
3/8 Hardened Plain Washer
|
| . . |
700707343
|
[2] |
SCREW
|
CAS
1/4-20 x 5/8 C Superseded by part number: 280641
|
| . . |
7773856
|
[2] |
BOLT,Hex, 1/4" - 20 x 2 3/4", Gr 5
|
CAS
1/4-20 x 2-3/4 C Superseded by part number: 280566
|
| . . |
413-520
|
[1] |
BOLT,Hex, 5/16" - 18 x 1-1/4", Gr 5
|
CAS
5/16-18 x 1-1/4 C Shear Bolt Superseded by part number: 87657
|
| . . |
703249
|
[2] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 x 1 C Superseded by part number: 88206
|
| . . |
413-628
|
[1] |
BOLT,Hex, 3/8" - 16 x 1-3/4", Gr 5
|
CAS
3/8-16 x 1-3/4 C Superseded by part number: 72187210, 9706689
|
| . . |
7701188
|
[4] |
BOLT,Hex, 1/2" - 13 x 1 1/4", Gr 5
|
CAS
1/2-13 x 1-1/4 C Superseded by part number: 87670
|
| . . |
700864
|
[1] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 2 1/4", Gr 5
|
CAS
3/8-16 x 2-1/4 RHSNB Superseded by part number: 280514
|
| . . |
7883325
|
[2] |
BOLT,Hex, 5/16" - 18 x 3/4", Gr 120M
|
CAS
5/16-18 x 3/4 HWHMS Superseded by part number: 121-115
|
| . . |
7774839
|
[4] |
LOCK NUT
|
CAS
1/4-20 HTLN Superseded by part number: 280129
|
| . . |
231-4115
|
[3] |
NUT,5/16"-18, GB
|
CAS
5/16-18 HTLN Superseded by part number: 280736
|
