凯斯零件查询(8450) - CASE IH ROUND BALER (1/88-12/93) (042) - ELECTRICAL SENSOR AND ACTUATOR ASSEMBLY, SERIAL NUMBER CFH0015275 AND ON Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
766 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
751487
|
[9] |
CLAMP
|
CAS
Superseded by part number: 86632595
|
| 2. |
755744
|
[1] |
CLAMP
|
CAS
Superseded by part number: 86594406
|
| 3. |
700708971
|
[1] |
HARNESS
|
CAS
- Wiring, Front
|
| 4. |
700119161
|
[3] |
SWITCH
|
L
Assembly (S.N. CFH0015001 thru 0015766)
|
| 5. |
700710211
|
[2] |
ACTUATOR
|
IH
Switch Assembly
|
| 6. |
700116136
|
[1] |
SUPPORT
|
HFI
- Switch (S.N. CFH0015001 thru 0015766)
|
| 7. |
700708970
|
[1] |
HARNESS
|
CAS
- Wiring, Rear
|
| 8. |
700708965
|
[1] |
PLUG
|
CAS
|
| 9. |
700708964
|
[1] |
WIRE CONNECTOR
|
CAS
Connector - Male Superseded by part number: 87692802
|
| 10. |
700708963
|
[1] |
WIRE CONNECTOR
|
CAS
Connector - Female Superseded by part number: 87692817
|
| 11. |
700708761
|
[2] |
ELEC CONNECTOR,Female
|
IH
Connector - Female Superseded by part number: 87692855
|
| 12. |
700708760
|
[8] |
ELEC. TERMINAL PIN,18 - 20 SAE
|
IH
- Sleeve, Female Superseded by part number: 225123C1
|
| 13. |
700708757
|
[5] |
ELEC. TERMINAL PIN,18 - 16 SAE
|
CAS
Pin
|
| 14. |
700708079
|
[1] |
WIRE CONNECTOR
|
CAS
Receptacle Superseded by part number: 87702796
|
| 15. |
158758
|
[1] |
SPACER
|
HFI
(S.N. CFH0015767 and on) Superseded by part number: 568395R1
|
| 16. |
705657
|
[6] |
WASHER
|
CAS
3/8 Narrow Plain Washer Superseded by part number: 495-11041, 495-11041, NLS
|
| 17. |
700122574
|
[1] |
SUPPORT
|
CAS
- Actuator
|
| 18. |
700709996
|
[1] |
SWITCH
|
IH
Actuator
|
| 19. |
700710188
|
[4] |
SCREW
|
CAS
No. 6-32 x 3/4 CRPHMS
|
| 20. |
700710208
|
[1] |
ROTARY SWITCH
|
L
Switch Assembly
|
| 21. |
700122570
|
[1] |
SUPPORT
|
HFI
- Switch
|
| 22. |
700710189
|
[4] |
LOCK NUT
|
CAS
No. 6-32 LHSN
|
| 23. |
700710448
|
[1] |
CLAMP
|
CAS
- Line Superseded by part number: 237910
|
| 24. |
700710187
|
[4] |
WASHER
|
CAS
No. 6 Plain Washer
|
| 25. |
700710199
|
[2] |
GROMMET
|
CAS
|
| 26. |
701953
|
[2] |
SELF-TAP SCREW
|
CAS
5/16-18 x 3/4 HWHTCTS Superseded by part number: 172463
|
| 27. |
73528
|
[1] |
SELF-TAP SCREW
|
CAS
3/8-16 x 1-1/2 HWHTCTS
|
| . . |
7883325
|
[4] |
BOLT,Hex, 5/16" - 18 x 3/4", Gr 120M
|
CAS
5/16-18 x 3/4 HWHMS Superseded by part number: 121-115
|
| . . |
7883382
|
[1] |
BOLT,Hex, 3/8" - 16 x 1", Gr 120M
|
CAS
3/8-16 x 1 HWHMS Superseded by part number: 87034804
|
