凯斯零件查询(8450) - CASE IH ROUND BALER (1/88-12/93) (096) - HYDRAULIC, TENSION CONTROL, LEFT, ASSEMBLY, SERIAL NUMBER CFH0015275 AND ON Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
449 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700707286
|
[2] |
HOSE
|
CAS
- Hydraulic
|
| 2. |
700702722
|
[1] |
ELBOW
|
CAS
45 Degree Elbow Superseded by part number: 86512959
|
| 3. |
8046658
|
[1] |
TEE
|
CAS
- Straight Run (Includes O-Ring) Superseded by part number: 86513020
|
| 4. |
738468
|
[2] |
O-RING
|
IH
|
| 5. |
8746455
|
[1] |
FITTING
|
CAS
Tee - Straight, Branch (Includes O-Ring) Superseded by part number: 163335
|
| 6. |
700708921
|
[1] |
CYLINDER
|
CAS
- Hydraulic, Tensioner - Lower Superseded by part number: 700712160
|
| 7. |
62653
|
[1] |
CLEVIS PIN
|
IH
5/8 x 3 Clevis Pin Superseded by part number: 87034825
|
| 8. |
700708068
|
[2] |
CLEVIS PIN,15.77mm OD x 68.66mm L
|
IH
5/8 x 2-1/2
|
| 9. |
700118823
|
[1] |
PIN
|
IH
|
| 10. |
700707262
|
[1] |
CYLINDER
|
CAS
- Hydraulic, Tensioner - Upper Superseded by part number: 700712161
|
| 11. |
396-21066
|
[2] |
WASHER,16.66mm ID x 33.33mm OD x 4.27mm Thk
|
CAS
5/8 Hardened Plain Washer Superseded by part number: 87613283
|
| . . |
7883382
|
[1] |
BOLT,Hex, 3/8" - 16 x 1", Gr 120M
|
CAS
3/8-16 x 1 HWHMS Superseded by part number: 87034804
|
