纽荷兰零件查询(ISM N844) - ISM ENGINE (10.402.01[01]) - WATER PUMP New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
170 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | SBA145017730 | [1] | WATER PUMP | SBAIncl. 2 - 5 |
| 1. | SBA145017730R | [1] | REMAN-WATER PUMP | SBA |
| 1. | SBA145017730C | [1] | CORE-WATER PUMP | SBAReturn Number |
| 2. | SBA145146320 | [1] | PLATE | NHSet |
| 3. | SBA145996680 | [1] | GASKET | NH Superseded by part number: SBA145996681 |
| 4. | SBA064500030 | [4] | PLUG,3/8" | NH |
| 5. | SBA015300614 | [5] | SCREW | NH |
| 6. | SBA145996670 | [1] | GASKET | NHWater Pump, BSN 174557 Superseded by part number: SBA145996990 |
| 6. | SBA145996990 | [1] | GASKET | WICWater Pump, ASN 174557 |
| 7. | SBA011310635 | [4] | CAPTIVE WASHER SCREW,Hex, M6 x 35, Cl 8.8 | NH |
| 8. | 9804276 | [3] | FLANGE NUT,M6 x 1.0, Cl 8 | NH |
| 9. | SBA011310655 | [2] | BOLT,Hex, M6 x 55, Cl 8.8 | SBA |
| 10. | SBA145996710 | [1] | GASKET | NH Superseded by part number: 362952A1 |
| 11. | SBA145206220 | [1] | THERMOSTAT,71° C (160° F) | SBA1.875" OD x 2.2" H |
| 12. | SBA145216640 | [1] | HOUSING | SBAThermostat |
| 13. | SBA012100655 | [2] | STUD | SBA Superseded by part number: SBA012110655 |
| 14. | SBA145536050 | [1] | HOSE | NHRubber Superseded by part number: SBA145536051 |
| 15. | SBA067100022 | [2] | HOSE CLAMP | NH |
| 16. | SBA145226340 | [1] | COVER | SBA |
| 17. | SBA145996051 | [1] | GASKET | NH |
| 18. | SBA011510820 | [2] | CAPTIVE WASHER SCREW,Hex, M8 x 20, G5 | NH |
