沃尔沃零件查询861 Charge air cooling system 99006, 99719861 NoneNoneNoneAutodata Volvo online
广数供应链运营团队, 14 02月, 2025，浏览：
182 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 5. |
VOE4822277
|
[0001] |
Anchorage
|
H
|
| 6. |
VOE4822276
|
[0001] |
Anchorage
|
V
|
| 7. |
VOE4822279
|
[0002] |
Rubber bushing
|
|
| 8. |
VOE4822253
|
[0002] |
Stiffener
|
|
| 9. |
VOE4822252
|
[0002] |
Rubber cloth
|
|
| 1. |
VOE4774456
|
[0001] |
Charge air cooler
|
|
| 10. |
VOE13949278
|
[0013] |
Flange lock nut
|
SER NO -58088
|
| |
VOE13949278
|
[0014] |
Flange lock nut
|
SER NO 58089-
|
| 11. |
VOE13947542
|
[0009] |
Screw
|
SER NO -58088
|
| |
VOE13947542
|
[0008] |
Screw
|
SER NO 58089-
|
| 12. |
VOE60110304
|
[0004] |
Washer
|
|
| 13. |
VOE4822270
|
[0002] |
Brace
|
SER NO -58088
|
| |
VOE4822270
|
[0003] |
Brace
|
SER NO 58089-
|
| 14. |
VOE4822210
|
[0001] |
Tube
|
|
| 15. |
VOE4822208
|
[0001] |
Tube
|
|
| 16. |
VOE476829
|
[0002] |
Hose
|
|
| 2. |
VOE4822175
|
[0001] |
Anchorage
|
V
|
| 17. |
VOE13949099
|
[0004] |
O-ring
|
|
| 18. |
VOE4786233
|
[0001] |
Fan
|
SER NO - 59095
|
| |
VOE4786233
|
[0001] |
Fan
|
|
| 19. |
VOE4822182
|
[0001] |
Anchorage
|
|
| 20. |
VOE4822197
|
[0001] |
Anchorage
|
|
| 21. |
VOE466327
|
[0001] |
Hose
|
|
| 22. |
VOE466327
|
[0001] |
Hose
|
|
| 23. |
VOE943479
|
[0002] |
Hose clamp
|
|
| 24. |
VOE943480
|
[0002] |
Hose clamp
|
|
| 25. |
VOE943482
|
[0004] |
Hose clamp
|
|
| 26. |
VOE4822282
|
[0008] |
Flange half
|
|
| 3. |
VOE4822174
|
[0001] |
Anchorage
|
H
|
| 27. |
VOE940161
|
[0001] |
Hexagon screw
|
|
| 28. |
VOE955540
|
[0001] |
Hexagon screw
|
|
| 29. |
VOE13955894
|
[0001] |
Washer
|
|
| 30. |
VOE13961170
|
[0001] |
Washer
|
|
| 31. |
VOE4822284
|
[0001] |
Stiffener
|
|
| 32. |
VOE4822285
|
[0001] |
Rubber cloth
|
|
| 33. |
VOE4861549
|
[0001] |
Clamp
|
SER NO -58088
|
| 34. |
VOE952630
|
[0001] |
Clamp
|
SER NO -58088
|
| 35. |
VOE4861665
|
[0001] |
Anchorage
|
SER NO 58089-
|
| 36. |
VOE13945408
|
[0001] |
Nut
|
SER NO 58089-
|
| 4. |
VOE341041
|
[0002] |
Damping element
|
|
| 37. |
VOE955299
|
[0001] |
Hexagon screw
|
SER NO 58089-
|
