| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 1W-2431 | [1] | CLAMP-BAND | |
| 2. | 9X-2201 | [2] | CLAMP-HOSE | |
| 3. | 179-3361 | [1] | PIPE AS | |
| 4. | 180-0352 | [1] | PIPE AS | |
| 5. | 310-6814 | [1] | SUPPORT AS(SHIELD) | |
| 6. | 186-1425 | [1] | DUCT AS | |
| 7. | 186-5065 | [2] | CLAMP(STEPPED) | |
| 8. | 190-5938 | [1] | TUBE-FLEXIBLE | |
| 9. | 8T-4121 | [8] | WASHER-HARD(11X21X2.5-MM THK) | |
| 10. | 8T-4133M | [2] | NUT(M10X1.5-THD) | |
| 11. | 8T-4136M | [6] | BOLT(M10X1.5X25-MM) | |
| M | METRIC PART | |||
