| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 5. |
|
[0001] |
Bracket
|
|
| 6. |
VOE13946934
|
[0001] |
Screw
|
|
| 7. |
VOE13949278
|
[0001] |
Flange lock nut
|
|
| 8. |
VOE943469
|
[0006] |
Hose clamp
|
|
| 9. |
VOE6643737
|
[REQ] |
Pressure hose
|
L = 1400
|
| 1. |
VOE4823997
|
[0001] |
Pump
|
|
| 10. |
VOE6643734
|
[0001] |
Cross Piece
|
|
| 11. |
VOE6643737
|
[REQ] |
Pressure hose
|
L = 750
|
| 12. |
VOE6643737
|
[REQ] |
Pressure hose
|
L = 2600
|
| 13. |
|
[0012] |
Strip
|
|
| 14. |
VOE4823919
|
[0002] |
Relief valve
|
|
| 15. |
VOE4823918
|
[0002] |
Nut
|
|
| 16. |
VOE11709847
|
[0002] |
Nozzle
|
|
| 17. |
|
[0001] |
Bracket
|
H.
|
| 18. |
|
[0001] |
Bracket
|
V.
|
| 19. |
VOE13940090
|
[0006] |
Washer
|
|
| 2. |
VOE941267
|
[0001] |
Plug
|
|
| 20. |
VOE955246
|
[0006] |
Hexagon screw
|
|
| 21. |
VOE4823998
|
[0001] |
Relay
|
R
|
| 22. |
VOE13940090
|
[0001] |
Washer
|
|
| 23. |
VOE969278
|
[0001] |
Six point socket screw
|
|
| 24. |
VOE4823999
|
[0001] |
Tool
|
|
| 3. |
VOE947457
|
[0001] |
Clamp
|
|
| 4. |
|
[0001] |
Bracket
|
|
