| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 344-2731 | [1] | MODULE GP-DISPLAY(WORK AREA VISUAL SYSTEM) | |
| 102-8805 | [1] | KIT-RECEPTACLE(6-PIN) | ||
| (INCLUDES RECEPTACLE AS & WEDGE) | ||||
| 8T-8729 | [5] | PIN-CONNECTOR(16-GA TO 18-GA) | ||
| 8T-8737 | [1] | PLUG-SEAL | ||
| 2. | 261-3222 | [1] | MOUNTING GP-DISPLAY(WORK AREA VISUAL SYSTEM) | |
| 259-4397 | [1] | CLAMP(MONITOR MOUNT) | ||
| 259-4399 | [2] | BASE | ||
| 3. | 4B-4274 | [4] | WASHER(5.5X13X1.2-MM THK) | |
| 4. | 8T-0288M | [4] | BOLT(M5X0.8X12-MM) | |
| M | METRIC PART | |||
