| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 4. |
VOE11993076
|
[1] |
Felt ring
|
|
| 5. |
VOE356844
|
[1] |
Guide
|
|
| 6. |
VOE350008
|
[1] |
Spring
|
|
| 7. |
VOE342333
|
[1] |
Spring retainer
|
|
| 8. |
VOE1695279
|
[1] |
Piston rod
|
|
| |
VOE1505054
|
[1] |
Brake cylinder
|
|
| 9. |
VOE342336
|
[1] |
Diaphragm
|
|
| 10. |
VOE1696532
|
[1] |
Cover
|
|
| 11. |
VOE342325
|
[1] |
Clamp
|
|
| 12. |
VOE342324
|
[1] |
O-ring
|
|
| 13. |
VOE351383
|
[1] |
Bushing
|
|
| 14. |
VOE342328
|
[0001] |
Spring
|
|
| 15. |
VOE1518497
|
[0001] |
Retainer
|
|
| 16. |
VOE11000012
|
[0008] |
Screw
|
|
| 17. |
VOE351381
|
[0004] |
Plug
|
|
| 18. |
VOE349106
|
[0001] |
Nut
|
|
| 1. |
VOE1517234
|
[1] |
Housing
|
|
| 2. |
VOE1518495
|
[1] |
Piston
|
|
| 3. |
VOE342327
|
[1] |
O-ring
|
|
