神钢零件查询(6D15-T) - MITSUBISHI DIESEL ENGINE - K909 II & K909LC II EXCAVATORS (1/87-12/06) (00-022) - EXHAUST MANIFOLD Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
770 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-3. | VAME070519 | [1] | EXHAUST MANIFOLD | KOBEXHAUST MANIFOLD ASSY,FOR M1 ONLY |
| . . | VAME070893 | [1] | FOR M8 ONLY | |
| 1. | VAME070487 | [1] | MANIFOLD,EXH,FOR M1 ONLY | |
| . . | VAME070896 | [1] | FOR M8 ONLY | |
| 3. | VAMF407728 | [4] | STUD | KOBSTUD 10X30 Superseded by part number: 134865A1 |
| 4. | VAME033496 | [6] | GASKET | KOBGASKET,EXH MANIF Superseded by part number: VAME073957 |
| 7. | VAMH004054 | [12] | NUT | KOB Superseded by part number: 134868A1 |
| 15. | VAME047329 | [1] | INSULATOR,HEAT,FOR M8 ONLY | |
| . . | VAME070989 | [1] | INSULATOR | KOBRE,FOR M1 ONLY |
| 15A. | VAME070990 | [1] | INSULATOR | KOBINSULATOR,HEAT FR,FOR M1 ONLY |
| 16. | VAMH000392 | [11] | BOLT | KOBBOLT,W/WSR 8X12 |
| 17. | VAMH000676 | [2] | SCREW | KOBBOLT,FLANGE 10X20,FOR M1 ONLY |
| 18. | VAMS456761 | [2] | SPACER SPACER T=6,FOR M1 ONLY | SPACER SPACER T=6,FOR M1 ONLY |
