凯斯零件查询(8610) - CASE IH BALE PROCESSOR (1/86-12/00) (9-08) - WARNING LIGHT KIT ASSEMBLY, HK50511 WARNING LIGHT KIT COMPLETE, TO BE ORDERED THRU WHOLEGOODS ONLY Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
321 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . . |
HK50511
|
[1] |
WARNING LIGHT KIT COMPLETE
|
|
| 1. |
700710290
|
[1] |
LAMP, TAIL
|
IH
LIGHT - tail
|
| 2. |
700117985
|
[3] |
GUARD
|
HFI
- light
|
| 3. |
7702012
|
[7] |
SELF-TAP SCREW,3/8" - 16 x 1"
|
CAS
3/8-16 X 1 HWHTCTS
|
| 4. |
700703825
|
[4] |
CLAMP
|
HFI
- line
|
| 5. |
433-612
|
[8] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 3/4", Gr 5
|
CAS
Superseded by part number: 280430
|
| 6. |
232-5316
|
[8] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| 7. |
700117984
|
[2] |
ANGLE
|
HFI
- mounting, light
|
| 8. |
700708036
|
[2] |
SIDE LAMP ASSY
|
IH
LIGHT - flasher (Includes item 9) Superseded by part number: 130609
|
| 9. |
700711749
|
[1] |
LENS
|
CAS
- flasher Superseded by part number: 71193862
|
| 10. |
700708584
|
[1] |
HARNESS
|
CAS
- wiring
|
| 11. |
7021728
|
[2] |
STRAP
|
CAS
TIE - cable Superseded by part number: 529070, 529070, NLS
|
