| 1. |
700122793
|
[1] |
SHIELD
|
HFI
- rotor
|
| 2. |
413-828
|
[3] |
BOLT,Hex, 1/2" - 13 x 1-3/4", Gr 5
|
CAS
Superseded by part number: 9707516, 72187217
|
| 3. |
705541
|
[3] |
WASHER,0.53" ID x 1.06" OD x 0.14" Thk
|
CAS
1/2 HARDENED PLAIN WASHER
|
| 4. |
231-5348
|
[19] |
FLANGE NUT,Flg, 1/2"-13
|
CAS
1/2-13 HFTLN GR/G Superseded by part number: 86521610
|
| 5. |
700122790
|
[1] |
SHIELD
|
HFI
- upper
|
| 6. |
433-820
|
[16] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 1/4", Gr 5
|
CAS
1/2-13 X 1-1/4 RHSNB Superseded by part number: 87868
|
| 7. |
700117372
|
[1] |
PANEL
|
HFI
- end, rotor
|
| 8. |
700118628
|
[1] |
FLANGE
|
IH
- bearing
|
| 9. |
712158
|
[1] |
SPHERICAL BEARING,2" ID x 100 mm OD
|
L
BEARING - spherical Superseded by part number: 47577203
|
| 10. |
714360
|
[1] |
FLANGED BEARING
|
IH
FLANGE - bearing, inner
|
| 11. |
7852866
|
[1] |
BUSHING
|
CAS
2 X 18 GAUGE NRMB
|
| 12. |
740407
|
[3] |
BRUSH, COMMUTATOR
|
CAS
2 X 10 GAUGE NRMB
|
| 13. |
413-664
|
[1] |
BOLT,Hex, 3/8" - 16 x 4", Gr 5
|
CAS
3/8-16 X 4 C Superseded by part number: 80012047
|
| 14. |
232-5316
|
[5] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| 15. |
700707932
|
[1] |
UNIVERSAL JOINT
|
IH
DRIVELINE WITH CLUTCH - implement half
|
| 16. |
700707931
|
[1] |
UNIVERSAL JOINT
|
IH
DRIVELINE - tractor half
|
| 17. |
708081
|
[1] |
SET SCREW,Sq Hd, 1/2"-13 x 1 1/4"
|
CAS
1/2-13 X 1-1/4 CPSQHSS
|
| 18. |
425-108
|
[1] |
NUT,1/2" - 13, Gr 5
|
CAS
NUT, , Hex 1/2"-13, G5 Superseded by part number: 280431
|
| 19. |
700706849
|
[2] |
LATCH
|
CAS
CLAMP - fastener
|
| 20. |
434-616
|
[4] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 X 1 RHSNB Superseded by part number: 80280503
|
| 21. |
340-1108
|
[4] |
SCREW,Cross Pan Hd, #10-24 x 1/2"
|
CAS
#10-24 X 1/2 CRPHMS
|
| 22. |
492-11010
|
[4] |
LOCK WASHER,#10
|
CAS
WASHER, LOCK, #10 Superseded by part number: 80684
|
| 23. |
225-14110
|
[4] |
NUT,#10-24
|
CAS
Superseded by part number: 87304
|
| 24. |
700117332
|
[1] |
SHIELD
|
HFI
- driveline
|
| 25. |
700117386
|
[2] |
SUPPORT
|
HFI
- shield
|
| 26. |
700117388
|
[1] |
PIN
|
HFI
- pivot
|
| 27. |
38-31212
|
[2] |
PIN,3/16" x 3/4", Coiled
|
CAS
Superseded by part number: 438-31212
|
| 28. |
6595805
|
[1] |
BUCKET TOOTH KEY
|
IH
1/2 X 1/2 X 4 KEY
|
