| 1. |
434-616
|
[2] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 X 1 RHSNB Superseded by part number: 80280503
|
| 2. |
496-81010
|
[6] |
WASHER
|
CAS
3/8 HARDENED WIDE PLAIN WASHER Superseded by part number: 86625244
|
| 3. |
232-5316
|
[7] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| 4. |
700124908
|
[2] |
GUIDE
|
HFI
|
| 5. |
700706849
|
[2] |
LATCH
|
CAS
|
| 6. |
8701237
|
[2] |
BOLT
|
CAS
1/2-13 X 1-1/2 HFS GR8
|
| 7. |
700711557
|
[8] |
WASHER
|
CAS
1/2 HARDENED WIDE PLAIN WASHER
|
| 8. |
231-5348
|
[12] |
FLANGE NUT,Flg, 1/2"-13
|
CAS
1/2-13 HFTLN GR/G Superseded by part number: 86521610
|
| 9. |
433-820
|
[8] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 1/4", Gr 5
|
CAS
1/2-13 X 1-1/4 RHSNB Superseded by part number: 87868
|
| 10. |
705541
|
[8] |
WASHER,0.53" ID x 1.06" OD x 0.14" Thk
|
CAS
1/2 HARDENED PLAIN WASHER
|
| 11. |
700136013
|
[1] |
PLATE
|
HFI
WA - Mtg, front
|
| 12. |
6805055
|
[2] |
SEAL
|
CAS
(10 foot bulk)
|
| 13. |
700124987
|
[1] |
SHIELD
|
HFI
- drive
|
| 14. |
700124988
|
[2] |
STRAP
|
HFI
|
| 15. |
433-612
|
[2] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 3/4", Gr 5
|
CAS
Superseded by part number: 280430
|
| 16. |
409-7612
|
[2] |
BOLT,3/8"-16 x 1.09" OAL
|
CAS
3/8-16 X 3/4 HWHMS Superseded by part number: 72187187, 255918
|
| 17. |
700124989
|
[1] |
SHAFT
|
HFI
|
| 18. |
63-31010
|
[2] |
SCREW,Hex Wash Hd, #10-24 x 5/8"
|
CAS
#10-24 X 5/8 HWHMS
|
| 19. |
225-14110
|
[2] |
NUT,#10-24
|
CAS
Superseded by part number: 87304
|
| 20. |
700710984
|
[2] |
SCREW,Hex Flg, 1/2" x 1 1/4", G8 NC
|
CAS
1/2-13 X 1-1/4 HFS GR8
|
| 21. |
700125001
|
[1] |
PLATE
|
HFI
- rear
|
| 22. |
51318
|
[2] |
BEARING
|
IH
- spherical Superseded by part number: 668718R92, 47577169
|
| 23. |
50583
|
[4] |
FLANGED BEARING
|
IH
Superseded by part number: 86979948
|
| 24. |
700715849
|
[1] |
JOINT
|
CAS
DOUBLE - U-Joint ASM
|
| 25. |
708081
|
[1] |
SET SCREW,Sq Hd, 1/2"-13 x 1 1/4"
|
CAS
1/2-13 X 1-1/4 CPSQHSS
|
| 26. |
425-108
|
[1] |
NUT,1/2" - 13, Gr 5
|
CAS
NUT, , Hex 1/2"-13, G5 Superseded by part number: 280431
|
| 27. |
6595805
|
[1] |
BUCKET TOOTH KEY
|
IH
1/2 X 4 KEY
|
| 28. |
413-664
|
[1] |
BOLT,Hex, 3/8" - 16 x 4", Gr 5
|
CAS
3/8-16 X 4 C Superseded by part number: 80012047
|
