沃尔沃零件查询AQD70D; TAMD70D; TAMD70ECooling SystemHeat Exchanger and Thermostat with Installation ComponentsEPC Volvo Penta Parts catalog
广数供应链运营团队, 14 02月, 2025，浏览：
638 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
824113
|
[1] |
Housing
|
|
| 2. |
951961
|
[1] |
Spring pin
|
|
| 3. |
824287
|
[1] |
Insert
|
|
| 4. |
925091
|
[1] |
O-ring
|
|
| 5. |
824313
|
[2] |
Gasket
|
|
| 6. |
837721
|
[1] |
End plate
|
|
| 7. |
955526
|
[8] |
Hexagon screw
|
|
| 8. |
823660
|
[2] |
Zinc electrode
|
|
| 9. |
823661
|
[2] |
Zinc anode
|
|
| 10. |
823662
|
[2] |
Plug
|
|
| 11. |
824305
|
[1] |
Bracket
|
|
| 12. |
955560
|
[1] |
Hexagon screw
|
|
| 13. |
940280
|
[1] |
Spring washer
|
|
| 14. |
940135
|
[2] |
Hexagon screw
|
|
| 15. |
941907
|
[10] |
Spring washer
|
|
| 16. |
955533
|
[4] |
Hexagon screw
|
|
| 17. |
941907
|
[4] |
Spring washer
|
|
| 18. |
820232
|
[1] |
Sign
|
|
| 19. |
950210
|
[3] |
Cross recessed screw
|
|
| 20. |
192618
|
[1] |
Hose
|
L=250mm
|
| 21. |
321973
|
[1] |
Filler cap
|
|
| 22. |
7743260_046
|
|
connection
|
|
| 23. |
82745
|
[4] |
Shut-off cock
|
|
| 24. |
7743260_046
|
|
cover
|
|
| 25. |
7743260_046
|
|
induction manifold and after cooler
|
|
| 25. |
|
|
|
|
| 26. |
824136
|
[1] |
Thermostat housing
|
|
| 27. |
420162
|
[1] |
Seal
|
|
| 28. |
820604
|
[1] |
Gasket
|
|
| 29. |
940134
|
[4] |
Hexagon screw
|
|
| 30. |
941909
|
[4] |
Spring washer
|
|
| 31. |
875788
|
[2] |
Thermostat kit
|
70°
|
| 31. |
875787
|
[2] |
Thermostat kit
|
76°
|
| 32. |
416033
|
[2] |
Sealing ring
|
|
| 33. |
824235
|
[1] |
Cap
|
|
| 34. |
955540
|
[3] |
Hexagon screw
|
|
| 35. |
942336
|
[3] |
Spring washer
|
|
| 36. |
952077
|
[3] |
Plug
|
|
| 37. |
180761
|
[2] |
Plug
|
|
| 38. |
11996
|
[2] |
Gasket
|
|
| 39. |
82744
|
[1] |
Shut-off cock
|
|
| 40. |
821032
|
[2] |
Hose connection
|
|
| 41. |
420171
|
[2] |
Gasket
|
|
| 42. |
955525
|
[4] |
Hexagon screw
|
|
| 43. |
941907
|
[6] |
Spring washer
|
|
| 44. |
820800
|
[1] |
Pipe elbow
|
|
| 45. |
420171
|
[1] |
Gasket
|
|
| 46. |
955525
|
[1] |
Hexagon screw
|
L=25mm
|
| 46. |
940159
|
[1] |
Hexagon screw
|
L=32mm
|
| 47. |
836169
|
[2] |
Gasket
|
|
| 48. |
952077
|
[1] |
Plug
|
|
| 49. |
824292
|
[1] |
Hose
|
|
| 50. |
824293
|
[1] |
Hose
|
|
| 51. |
943479
|
[4] |
Hose clamp
|
|
| 52. |
7743260_042
|
|
circulation pump
|
|
| 53. |
7743260_048
|
|
exhaust manifold
|
|
