沃尔沃零件查询AQD70D; TAMD70D; TAMD70ECooling SystemInduction Manifold and After Cooler with Installation ComponentsEPC Volvo Penta Parts catalog
广数供应链运营团队, 14 02月, 2025,浏览:
958 次


| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
837250
|
[1] |
Inlet manifold
|
|
| 2. |
191026
|
[1] |
Plug
|
|
| 3. |
421071
|
[2] |
Gasket
|
|
| 4. |
955530
|
[2] |
Hexagon screw
|
L=83mm
|
| 4. |
940136
|
[14] |
Hexagon screw
|
L=64mm
|
| 4. |
955525
|
[2] |
Hexagon screw
|
L=25mm
|
| 5. |
941907
|
[18] |
Spring washer
|
|
| 6. |
824140
|
[1] |
Insert
|
|
| 7. |
925064
|
[1] |
O-ring
|
|
| 8. |
824301
|
[2] |
Gasket
|
|
| 9. |
837027
|
[1] |
Cover
|
|
| 10. |
955527
|
[8] |
Hexagon screw
|
|
| 11. |
941907
|
[8] |
Spring washer
|
|
| 12. |
837025
|
[1] |
Connector
|
|
| 13. |
858471
|
[1] |
Hose
|
L=110mm
|
| 14. |
994562
|
[2] |
Hose clamp
|
|
| 15. |
925091
|
[1] |
O-ring
|
|
| 16. |
955525
|
[3] |
Hexagon screw
|
|
| 17. |
941907
|
[3] |
Spring washer
|
|
| 18. |
82745
|
[1] |
Shut-off cock
|
|
| 19. |
823661
|
[1] |
Zinc anode
|
|
| 20. |
823661
|
[1] |
Zinc anode
|
|
| 21. |
823662
|
[1] |
Plug
|
|
| 22. |
836169
|
[1] |
Gasket
|
|
| 23. |
837308
|
[1] |
Flange
|
See group 3
|
| 24. |
837309
|
[1] |
Gasket
|
|
| 25. |
940100
|
[2] |
Hexagon screw
|
|
| 26. |
941906
|
[2] |
Spring washer
|
|
| 27. |
824310
|
[1] |
Gasket
|
|
| 28. |
7743260_032
|
|
heat exchanger
|
|
