纽荷兰零件查询(CV2000) - VIBRATORY ROLLER (10-002-00[01]) - HYDRAULIC CIRCUIT - VIBRATION New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
576 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 9. | ND062135 | [1] | HYD CONNECTOR | STA |
| 11. | ND062223 | [3] | FITTING | STA |
| 13. | ND062433 | [1] | RESTRICTOR | STA |
| 15. | ND092609 | [2] | FLANGE | STA |
| 20. | ND062009 | [4] | FLANGE | STA |
| 21. | ND079934 | [2] | O-RING | STA |
| 26. | ND061911 | [1] | HOSE | STA |
| 28. | ND061933 | [1] | HOSE | STA |
| 29. | ND061945 | [1] | HOSE | STA |
| 31. | ND061919 | [1] | HOSE | STA |
| 32. | ND061918 | [1] | HOSE | STA |
| 37. | ND034063 | [16] | BOLT | STA |
| 48. | ND106910 | [6] | STRAP | STA370mm |
