纽荷兰零件查询(CV2000) - VIBRATORY ROLLER (10-003-00[01]) - HYDRAULIC CIRCUIT, TRAVEL - DRUM New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
300 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | ND103147 | [1] | SUPPORT | STA |
| 5. | ND052985 | [3] | STUD | STA |
| 7. | ND104741 | [1] | BRACKET | STA |
| 17. | ND067795 | [1] | VALVE | STA |
| 22. | ND062153 | [2] | HYD CONNECTOR | STA |
| 23. | ND062173 | [3] | HYD CONNECTOR | STA |
| 24. | ND062196 | [1] | HYD CONNECTOR | STA |
| 27. | ND062135 | [1] | HYD CONNECTOR | STA |
| 28. | ND062136 | [2] | HYD CONNECTOR | STA |
| 32. | ND062425 | [2] | HYD CONNECTOR | STA |
| 33. | ND062366 | [3] | ELBOW | STA |
| 35. | ND062403 | [1] | TEE | STA |
| 38. | ND062314 | [1] | TEE | STA |
| 39. | ND062426 | [1] | HYD CONNECTOR | STA |
| 40. | ND062338 | [1] | TEE | STA |
| 41. | ND062392 | [1] | HYD CONNECTOR | STA |
| 43. | ND062322 | [1] | HYD CONNECTOR | STA |
| 44. | ND062324 | [1] | HYD CONNECTOR | STA |
| 46. | ND062452 | [1] | PLUG | STA |
| 49. | ND062456 | [1] | HYD CONNECTOR | STA |
| 52. | ND062277 | [1] | QUICK FEMALE COUPLING | STA Superseded by part number: ND112940 |
| 53. | ND062280 | [1] | QUICK MALE COUPLING | STA Superseded by part number: ND112941 |
| 56. | ND062008 | [4] | HALF-COLLAR | STA |
| 57. | ND062009 | [4] | FLANGE | STA |
| 59. | ND079933 | [2] | O-RING | STA |
| 60. | ND079934 | [2] | O-RING | STA |
| 71. | ND061912 | [1] | HOSE | STA |
| 72. | ND061698 | [1] | HOSE | STA |
| 78. | ND061910 | [1] | HOSE | STA |
| 81. | ND061907 | [1] | HOSE | STA |
| 82. | ND061906 | [1] | HOSE | STA |
| 85. | ND061921 | [1] | HOSE | STA |
| 86. | ND061920 | [1] | HOSE | STA |
| 96. | ND064799 | [1] | CLAMP | STA |
| 97. | ND064826 | [1] | ADJUSTING SLEEVE | STA |
| 112. | ND024236 | [2] | BOLT | STA |
| 115. | ND024235 | [2] | BOLT | STA |
| 121. | ND024259 | [8] | BOLT | STA |
| 122. | ND021197 | [2] | BOLT | STA |
| 125. | ND034063 | [8] | BOLT | STA |
| 128. | ND021309 | [2] | BOLT | STA |
| 132. | ND021847 | [3] | NUT | STA |
| 137. | ND029309 | [3] | SPRING WASHER | STA |
| 138. | ND029248 | [6] | WASHER | STA |
| 142. | ND035941 | [2] | WASHER | STA |
| 144. | ND035942 | [2] | WASHER | STA |
