沃尔沃零件查询AQD70D; TAMD70D; TAMD70ETransmissionsLifting Cylinder with Connecting ComponentsEPC Volvo Penta Parts catalog
广数供应链运营团队, 14 02月, 2025，浏览：
334 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
832376
|
[1] |
Lifting cylinder
|
|
| 2. |
832245
|
[1] |
Lifting cylinder
|
S.B
|
| 3. |
832392
|
[2] |
Cover
|
|
| 4. |
950570
|
[4] |
Pin
|
|
| 5. |
832340
|
[4] |
Bushing
|
|
| 6. |
955894
|
[10] |
Washer
|
|
| 7. |
955826
|
[10] |
Hexagon nut
|
|
| 8. |
832341
|
[2] |
Gasket
|
|
| 9. |
959969
|
[12] |
Screw
|
|
| 10. |
943152
|
[4] |
Nut
|
|
| 11. |
942336
|
[16] |
Spring washer
|
|
| 12. |
945093
|
[4] |
O-ring
|
|
| 13. |
959953
|
[10] |
Hexagon screw
|
|
| 14. |
832262
|
[2] |
Bushing
|
|
| 15. |
832377
|
[2] |
Coupling piece
|
|
| 16. |
956572
|
[4] |
Hex. socket screw
|
|
| 17. |
955980
|
[2] |
O-ring
|
|
| 18. |
960202
|
[2] |
O-ring
|
|
| 19. |
943907
|
[6] |
Gasket
|
|
| 20. |
957030
|
[4] |
Nipple
|
|
| 21. |
945355
|
[2] |
Fitting
|
|
| 22. |
956969
|
[6] |
Ferrule
|
|
| 23. |
956983
|
[6] |
Fitting nut
|
|
| 24. |
956967
|
[2] |
Ferrule
|
|
| 25. |
941521
|
[2] |
Fitting nut
|
|
| 26. |
944262
|
[1] |
Clutch
|
|
| 27. |
944525
|
[1] |
T-nipple
|
|
| 28. |
945356
|
[2] |
Clutch
|
|
| 29. |
945357
|
[3] |
Elbow nipple
|
For AQD70B spec 867167, AQD70C spec 867224, AQD70CL spec 867266
|
| 30. |
832378
|
[1] |
Tube
|
|
| 31. |
832379
|
[1] |
Tube
|
|
| 32. |
|
|
|
See group 3
|
| 33. |
832380
|
[1] |
Hydraulic hose, hose
|
For AQD70B spec 867167, AQD70C spec 867224, AQD70CL spec 867266., L=600mm
|
| 33. |
|
|
|
L=600mm
|
| 34. |
832381
|
[2] |
Hydraulic hose, hose
|
For AQD70B spec 867167, AQD70C spec 867224, AQD70CL spec 867266., L=750mm
|
| 34. |
|
|
|
L=750mm
|
