凯斯零件查询(RB454) - CASE IH ROUND BALER (7/07-1/14) (18.04) - DIA KIT, SAFETY CHAIN KIT Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
540 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
87018297
|
[1] |
DIA KIT, HARVESTER
|
PA
Safety Chain, Includes: Installation Instructions
|
| 2. |
86607695
|
[1] |
SPACER,17.48mm ID x 28.6mm OD x 20.6mm L
|
NH
|
| 4. |
814-16150
|
[1] |
BOLT,Hex, M16 x 2 x 150mm, Cl 8.8
|
IH
Superseded by part number: 362573
|
| 6. |
636422
|
[1] |
WASHER,16.66mm ID x 69.85mm OD
|
NH
21/32" ID x 2-3/4" OD x 3/8" Thk
|
| 8. |
130358
|
[3] |
WASHER,16.28mm ID x 38.35mm OD x 4.11mm Thk
|
NH
Hardened, 5/8"
|
| 10. |
832-46416
|
[1] |
NUT,M16 x 2, Cl 8
|
CAS
Superseded by part number: 86000441
|
| 11. |
850116
|
[1] |
CHAIN
|
NH
Safety
|
