沃尔沃零件查询EC135B Servo system, remote control valveSER NO 20001-200798277147-NoneNoneNoneNoneAutodata Volvo online
广数供应链运营团队, 14 02月, 2025，浏览：
198 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| |
VOE14510417
|
[1] |
Remote control valve
|
LH,S/N -20036
|
| |
VOE14557286
|
[1] |
Remote control valve
|
LH,S/N 20037-
|
| |
VOE14510418
|
[1] |
Remote control valve
|
RH,S/N -20036
|
| |
VOE14557287
|
[1] |
Remote control valve
|
RH,S/N 20037-
|
| 1. |
SA8230-37050
|
[1] |
Casing
|
|
| 2. |
SA8230-37150
|
[1] |
Plate
|
|
| 3. |
SA8230-19731
|
[2] |
Washer
|
|
| 4. |
SA8230-37060
|
[1] |
O-ring
|
|
| 5. |
VOE11706967
|
[2] |
Screw
|
|
| 6. |
SA8230-25940
|
[1] |
Spring pin
|
|
| 7. |
SA8230-37100
|
[1] |
Bushing
|
|
| 8. |
SA8230-37140
|
[1] |
Plate
|
|
| 9. |
VOE14540762
|
[4] |
Spool
|
|
| 10. |
SA8230-28800
|
[4] |
Plug
|
|
| 11. |
SA8230-19790
|
[4] |
Rod
|
|
| 12. |
SA8230-20110
|
[4] |
Seal
|
|
| 13. |
VOE983509
|
[4] |
O-ring
|
|
| 14. |
SA8230-36650
|
[4] |
Valve seat
|
|
| 15. |
SA8230-19690
|
[4] |
Washer
|
|
| 16. |
VOE14512873
|
[2] |
Spring
|
S/N -20036
|
| |
VOE14540766
|
[2] |
Spring
|
S/N 20037-
|
| 17. |
VOE14512874
|
[2] |
Spring
|
S/N -20036
|
| |
VOE14541091
|
[2] |
Spring
|
S/N 20037-
|
| 18. |
SA8230-36770
|
[4] |
Spring
|
|
| 19. |
SA8230-20040
|
[1] |
Joint
|
|
| 20. |
SA8230-37120
|
[1] |
Plate
|
|
| 21. |
SA8230-19940
|
[1] |
Nut
|
|
| 22. |
SA8230-19950
|
[1] |
Lock nut
|
|
| 23. |
VOE14500122
|
[1] |
Control lever
|
|
| 24. |
VOE14500125
|
[1] |
Bushing
|
|
| 25. |
VOE14500124
|
[1] |
Pin
|
|
| 26. |
VOE14514021
|
[1] |
Knob
|
LH,S/N -20036
|
| |
VOE14514026
|
[1] |
Knob
|
RH,S/N -20036
|
| 27. |
SA8230-20180
|
[1] |
Terminal
|
S/N -20036
|
| |
SA8230-20180
|
[1] |
Terminal
|
S/N 20037-
|
| 28. |
SA8230-20190
|
[1] |
Terminal
|
S/N -20036
|
| |
SA8230-20190
|
[1] |
Terminal
|
S/N 20037-
|
| 29. |
VOE14500561
|
[1] |
Housing
|
S/N -20036
|
| 30. |
VOE14500130
|
[1] |
Bellows
|
|
| 31. |
VOE14546296
|
[1] |
Knob
|
|
| 32. |
VOE14500126
|
[1] |
Housing
|
|
| |
VOE14500127
|
[1] |
Retainer
|
|
| |
VOE11428087
|
[4] |
Terminal
|
|
| |
VOE14500129
|
[4] |
Plug
|
|
| 100. |
SA8230-36840
|
[1] |
Sealing kit
|
|
