| 1. |
47462454
|
[1] |
WIRE HARNESS
|
NH
ISOBUS. YFN188618 and Prior Superseded by part number: 47938509
|
| 2. |
87688716
|
[4] |
ELEC CONNECTOR,Female, 3 Cavities
|
FAR
Stop/Tail/Hazard Lights
|
| 3. |
87418311
|
[3] |
ELEC CONNECTOR,Female, 3 Cavities
|
FAR
Bale Shape Sensor, LH
|
| 4. |
87695582
|
[1] |
ELEC CONNECTOR,Female, 2 Pole
|
RAC
Tail Gate, RH
|
| 5. |
87695549
|
[1] |
ELEC CONNECTOR,Female, 3 Cavities
|
RAC
Pressure Bypass Option
|
| 6. |
87695580
|
[1] |
ELEC CONNECTOR,Female, 3 Pole
|
BN
Pressure, Pre-Charge Option
|
| 7. |
47486969
|
[1] |
Option D, Red
|
ELEC CONNECTOR,Female 3 Cavities, Red
|
| 8. |
87694714
|
[1] |
ELEC CONNECTOR,Female, 6 Cavities
|
ZED
TBC Module Superseded by part number: 256348A1
|
| 9. |
82016219
|
[1] |
MULTIPOLE CONNECTOR,Female, 26 Pole
|
JES
Universal Control Module Superseded by part number: 87691969
|
| 10. |
87410946
|
[1] |
WIRE CONNECTOR,Female
|
RAC
Universal Control Module Superseded by part number: 87691970
|
| 11. |
82028493
|
[1] |
MULTIPOLE CONNECTOR,Female, 26 Pole
|
JES
Universal Control Module Superseded by part number: 87419488
|
| 12. |
82028495
|
[1] |
MULTIPOLE CONNECTOR,Female, 34 Pole
|
JES
Universal Control Module
|
| 13. |
84130757
|
[1] |
ELEC CONNECTOR,Female, 26 Cavities
|
FAR
Universal Control Module
|
| 14. |
84130760
|
[1] |
ELEC CONNECTOR,Female, 34 Cavities
|
FAR
Universal Control Module
|
| 15. |
47685284
|
[1] |
|
SPADE TERMINAL,Straight, M8
|
| 16. |
87693732
|
[1] |
LOCKING TAB,Wedge Lock
|
FAR
|
| 17. |
84074638
|
[1] |
LOCKING TAB,Locking Wedge, Green
|
ZED
|
| 18. |
84058193
|
[1] |
LOCKING TAB,Wedge Lock
|
ZED
|
| 19. |
84391165
|
[1] |
HOUSING,Receptacle
|
BN
|
| 20. |
84074639
|
[1] |
LOCKING TAB,Wedge Lock
|
ZED
Superseded by part number: 89842513
|
| 21. |
84277224
|
[1] |
|
LOCKING TAB,Wedge Lock
|
| 22. |
87694719
|
[1] |
LOCKING TAB,Wedge Lock
|
ZED
Superseded by part number: 258617A1
|
| 23. |
87601142
|
[1] |
ELEC CONNECTOR,Female, 6 Cavities
|
PLO
|
| 24. |
84128198
|
[1] |
HEAT SHIELD
|
GI
|
