| 1. |
47462454
|
[1] |
WIRE HARNESS
|
NH
ISOBUS, YFN188618 AND Prior Superseded by part number: 47938509
|
| 2. |
47618613
|
[2] |
Diagnostic
|
MULTIPOLE CONNECTOR,Female, 9 Cavities
|
| 3. |
87700152
|
[1] |
ELEC CONNECTOR,Female, 12 Cavities
|
RAC
Cap, Black
|
| 4. |
87696130
|
[1] |
ELEC CONNECTOR,Female, 12 Cavities
|
PLO
Base to C Options
|
| 5. |
87695580
|
[1] |
ELEC CONNECTOR,Female, 3 Pole
|
BN
Resistor, CAN Termination
|
| 6. |
82028495
|
[1] |
MULTIPOLE CONNECTOR,Female, 34 Pole
|
JES
Universal Control Module
|
| 7. |
82028493
|
[1] |
MULTIPOLE CONNECTOR,Female, 26 Pole
|
JES
Universal Control Module Superseded by part number: 87419488
|
| 8. |
82016219
|
[1] |
MULTIPOLE CONNECTOR,Female, 26 Pole
|
JES
H-Bridge Superseded by part number: 87691969
|
| 9. |
84155775
|
[1] |
H-Bridge
|
MULTIPOLE CONNECTOR,Female, 24 Cavities
|
| 10. |
87699386
|
[1] |
MULTIPOLE CONNECTOR,Female, 24 Pole
|
BER
H-Bridge
|
| 11. |
87700154
|
[1] |
A Options, Brown
|
MULTIPOLE CONNECTOR,Female, 12 Cavities
|
| 12. |
87695550
|
[1] |
ELEC CONNECTOR,Female, 12 Cavities
|
BN
B Options, Green
|
| 13. |
87692853
|
[1] |
MULTIPOLE CONNECTOR,Female, 4 Pole
|
NH
Relay, Power
|
| 14. |
47618630
|
[1] |
|
DUST CAP
|
| 15. |
87716303
|
[1] |
NUT,1.500" x 18 UNEF
|
ZED
|
| 16. |
87718624
|
[1] |
BOOT
|
GI
|
| 17. |
87698541
|
[1] |
LOCKING TAB,Wedge Lock, 12-Pin
|
ZED
|
| 18. |
84068583
|
[1] |
PLUG,12 - 16 Ga, White
|
ZED
Superseded by part number: 87695652
|
| 19. |
87695651
|
[1] |
LOCKING TAB,Wedge Lock
|
BN
|
| 20. |
84058092
|
[1] |
CONTACT HOUSING,120 Ohm Resistor
|
ZED
|
| 21. |
84147090
|
[1] |
LOCKING TAB,Wedge Lock
|
CUR
|
| 22. |
82028431
|
[1] |
LOCKING TAB,Wedge Lock
|
BAS
|
| 23. |
82017871
|
[1] |
RELAY,12V, 20A
|
BAS
Superseded by part number: 84411012
|
