凯斯零件查询(RB455) - CASE IH ROUND BALER - NORTH AMERICA (1/14-12/15) (62.140.AR[02]) - BALE DENSITY TAKE UP ARM, ROLLERS, SCRAPER, SILAGE, YGN193203 AND AFTER Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
201 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47689083
|
[1] |
ARM
|
NH
Take Up, with Single Density Cylinder
|
| 1. |
47963364
|
[1] |
ARM
|
NH
Take Up, with Dual Density Cylinders
|
| 2. |
84356720
|
[1] |
ROLL,88.9mm OD x 1142mm L
|
PLO
Front Serpentine, Loop, Incl 13
|
| 3. |
47512226
|
[1] |
ROLL
|
PLO
Rear Serpentine, Smooth, Incl 14
|
| 4. |
86516322
|
[2] |
SUPPORT
|
NH
Superseded by part number: 87654792
|
| 5. |
9823372
|
[2] |
SHAFT,1135mm L
|
NH
Incl 15
|
| 6. |
87040645
|
[1] |
ANGLE
|
PA
|
| 7. |
47527692
|
[4] |
SHIM,54mm OD x 0.4mm Thk
|
PLO
|
| 8. |
9845575
|
[1] |
SCRAPER BLADE
|
NH
|
| 9. |
86521602
|
[2] |
SUPPORT
|
NH
Superseded by part number: 87023400
|
| 10. |
9804258
|
[8] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 11. |
86050286
|
[4] |
FLANGE BOLT,M10 x 20mm, Cl 8.8
|
NH
|
| 12. |
86627635
|
[4] |
BOLT,Hex, M12 x 1.75 x 30mm, Cl 10.9
|
NH
|
| 13. |
84259867
|
[2] |
BALL BEARING,38.1mm ID x 80mm OD x 22mm W
|
PLO
|
| 14. |
47935418
|
[2] |
BEARING HOUSING
|
NH
Incl 13
|
| 15. |
130045
|
[2] |
PIN,5mm OD x 26mm L, Slotted
|
NH
|
