凯斯零件查询(RB455) - CASE IH ROUND BALER - NORTH AMERICA (1/14-12/15) (62.150.AB[01]) - STARTER ROLL Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
474 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47475711
|
[1] |
ROLL
|
NH
Starter, Hay and Silage, 2 Splines
|
| 1. |
47587935
|
[1] |
ROLL
|
NH
Starter, Hay and Silage, Optional, 1 Spline
|
| 2. |
86609558
|
[2] |
BEARING ASSY,45mm ID
|
NH
|
| 3. |
9804268
|
[8] |
BOLT,Hex, M12 x 40mm, Cl 8.8, Full Thd
|
NH
|
| 4. |
80717
|
[2] |
LUBE NIPPLE,45 Degree, 1/8" NPT x 7/8" lg
|
NH
|
| 5. |
47473621
|
[1] |
RAKE
|
PLO
Optional
|
| 6. |
47473637
|
[1] |
SHIM,17.5mm OD x 0.4mm Thk
|
PLO
Optional
|
| 7. |
374892
|
[4] |
CARRIAGE BOLT,M10 x 1.5 x 40mm, Cl 8.8
|
NH
|
| 8. |
140045
|
[4] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 9. |
9804278
|
[4] |
FLANGE NUT,M10 x 1.5, Cl 8
|
NH
|
