纽荷兰零件查询(D125C LT) - CRAWLER DOZER - TIER 4A (10/13-) (35.741.AA[01]) - LIFT CYLINDER New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
756 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 84389147 | [2] | LIFT CYLINDER,Double Acting, 50.8mm Rod, 488mm Stroke | BURIncl 2 - 6, 8 - 13 |
| 1. | 84389147R | [2] | REMAN-HYD CYLINDER | BUR1150M LT, 1150M WT/LGP, Both (12/12-), D125C LT, D125C WT/LGP, All CRAWLER DOZER - TIER 4A |
| 1. | 84389147C | [2] | CORE-HYD CYLINDER | BURReturn Number |
| 2. | 86982441 | [1] | SPECIAL BOLT | BUR |
| 3. | G109395 | [1] | SELF-TAP SCREW,Hex, #8 - 32 x 3/8" | CAS Superseded by part number: 86642312 |
| 4. | 219-1 | [2] | LUBE NIPPLE,1/8"-27 x .66 lg | CAS Superseded by part number: 80710 |
| 5. | 353-780 | [2] | PLUG,Sltd Hd, 7/8"-14, w/O-Ring | CASShipping Superseded by part number: 86625121 |
| 6. | D140029 | [4] | BUSHING,50.22mm ID x 60mm OD x 25.5mm L | CAS |
| 7. | 84479796 | [1] | SEAL KIT | BUR108.0 x 50.8; Incl 8 - 13 |
| 8. | D95144 | [1] | WIPER SEAL,50.77mm ID x 63.52mm OD x 7.92mm Thk | CASWiper |
| 9. | 1542876C1 | [1] | SEAL KIT | CASRod and Buffer Seal |
| 10. | G101533 | [1] | WEAR RING,Split, 50.8mm ID x 53.87mm OD x 25.15mm Thk | CAS |
| 11. | 87615483 | [1] | SEAL,100.05mm ID x 108.33mm OD x 4.85mm Thk | BURStatic Head |
| 12. | NSS | [1] | NOT SERVICED SEPARATELY | CONSEAL ASSY; Piston; 4-Piece; 108.0 Bore; Incl 7 |
| 13. | G110530 | [1] | RING | CASWear |
