纽荷兰零件查询(D125C LT) - CRAWLER DOZER - TIER 4A (10/13-) (35.741.AC[01]) - ANGLE CYLINDER New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
293 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 84402337 | [2] | HYDRAULIC CYLINDER,Double Acting, 63.5mm Rod, 465.7mm Stroke | BURAngle; Incl 2 - 8, 10 - 15 |
| 1. | 84402337R | [2] | REMAN-HYD CYLINDER | BURAngle |
| 1. | 84402337C | [2] | CORE-HYD CYLINDER | BURReturn Number |
| 2. | 86982443 | [1] | SPECIAL BOLT | BUR |
| 3. | G109395 | [1] | SELF-TAP SCREW,Hex, #8 - 32 x 3/8" | CAS Superseded by part number: 86642312 |
| 4. | 219-1 | [2] | LUBE NIPPLE,1/8"-27 x .66 lg | CAS Superseded by part number: 80710 |
| 5. | 353-780 | [2] | PLUG,Sltd Hd, 7/8"-14, w/O-Ring | CASShipping Superseded by part number: 86625121 |
| 6. | D23601 | [2] | HOUSING | CASSpherical Bearing 2.00" ID Superseded by part number: 86000739 |
| 7. | 49477 | [2] | RING, SNAP | NNA Superseded by part number: 100-21315, 100-21315, NLS |
| 8. | 100-21315 | [2] | SNAP RING,3.156", Int, #315 | CAS Superseded by part number: 9670291 |
| 9. | 84479825 | [1] | SEAL KIT | BUR114.3 x 63.5; Incl 10 - 15 |
| 10. | D95146 | [1] | WIPER SEAL,63.4mm ID x 76.22mm OD x 7.92mm Thk | CAS |
| 11. | 1542879C1 | [1] | SEAL KIT | IH |
| 12. | G109908 | [1] | BUSHING,63.5mm ID x 66.57mm OD x 25.15mm L | CASRod Bearing |
| 13. | NSS | [1] | NOT SERVICED SEPARATELY | CONSeal, Static Head, 114.3 Bore; Incl 9 |
| 14. | G103284 | [1] | GASKET | CASWear Ring |
