凯斯零件查询(RB455A) - UTILITY CASE IH ROUND BALER (1/10-12/14) (31.201.01[02]) - POWER TAKE OFF, 540 RPM, SHEAR BOLT, NORTH AMERICA Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
137 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47841215
|
[1] |
PTO
|
NH
540 RPM, Shearbolt, 1400nM, Incl 2 - 23
|
| 2. |
87518490
|
[1] |
YOKE
|
BEL
|
| 3. |
87517787
|
[1] |
U-JOINT SPIDER
|
BEL
Shearbolt
|
| 4. |
87520072
|
[1] |
YOKE
|
BEL
|
| 5. |
87517785
|
[1] |
BODY
|
BEL
|
| 6. |
87520073
|
[1] |
ROLL PIN
|
BEL
Superseded by part number: 87586147
|
| 7. |
47841229
|
[1] |
PTO SHAFT,1170mm L
|
NH
Front
|
| 8. |
47841232
|
[1] |
PTO SHAFT,1175mm L
|
NH
Rear
|
| 9. |
86625846
|
[1] |
PIN
|
NH
Superseded by part number: 87586150
|
| 10. |
274240
|
[1] |
YOKE
|
GI
|
| 11. |
87520105
|
[1] |
HUB ASSY.
|
BEL
Incl 20, 28
|
| 12. |
87520078
|
[1] |
SPIDER ,U-JOINT
|
BEL
Superseded by part number: 84355315
|
| 13. |
84383919
|
[1] |
SHIELD
|
PA
Front
|
| 14. |
87517775
|
[1] |
SHIELD
|
BEL
Front
|
| 15. |
NSS
|
[6] |
NOT SOLD SEPARAT
|
CON
Self-Tapping Screw
|
| 16. |
84383920
|
[1] |
SHIELD
|
PA
Rear
|
| 18. |
849471
|
[1] |
DANGER DECAL
|
NH
|
| 19. |
849472
|
[1] |
DANGER DECAL
|
NH
|
| 20. |
782083
|
[1] |
LOCK PIN
|
NH
Incl with 11
|
| 21. |
47841309
|
[1] |
PTO SHAFT
|
NH
Front, Incl 2 - 7
|
| 22. |
47841319
|
[1] |
PTO SHAFT
|
NH
Rear, Incl 8 - 12
|
| 23. |
47841325
|
[1] |
SHIELD
|
NH
Complete, Incl 23 - 27
|
| 28. |
PL
|
[1] |
PROCURE LOCALLY
|
BAS
Shearbolt, Incl with 11
|
