凯斯零件查询(RB455A) - UTILITY CASE IH ROUND BALER (1/10-12/14) (31.220.01) - GEARBOX MOUNTING Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
758 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84276562
|
[1] |
GEARBOX
|
NH
Main Drive, 540 RPM
|
| 2. |
86634418
|
[1] |
COUPLING
|
NH
Superseded by part number: 87661924
|
| 3. |
86637396
|
[2] |
WASHER,25.6mm ID x 35.3mm OD x 1mm Thk
|
NH
|
| 4. |
86979179
|
[4] |
WASHER,16.67mm ID x 34.93mm OD x 6.35mm Thk
|
NH
|
| 5. |
140048
|
[4] |
BELLEVILLE WASHER,M16 Bolt Size x 32mm OD x 2.8mm Thk
|
NH
|
| 6. |
86508583
|
[4] |
BOLT,Hex, M16 x 35mm, Cl 8.8, Full Thd
|
NH
Superseded by part number: 86529976
|
| 7. |
86637370
|
[2] |
SEAL,40mm ID x 52mm OD x 7mm Thk
|
NH
|
| 8. |
300643
|
[2] |
SNAP RING,M38, Int
|
NH
Superseded by part number: 11059776
|
| 9. |
86539157
|
[1] |
BREATHER,3/8" Gas
|
NH
|
| 10. |
62161
|
[2] |
LUBE NIPPLE,M8 x 1.25, Str
|
NH
|
