凯斯零件查询(RB455A) - UTILITY CASE IH ROUND BALER (1/10-12/14) (31.220.02) - GEARBOX, 540 RPM Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
401 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84276562
|
[1] |
GEARBOX
|
NH
|
| 2. |
84271931
|
[2] |
SNAP RING
|
NH
|
| 3. |
84271939
|
[8] |
BOLT
|
NH
|
| 4. |
86539214
|
[2] |
SHIM
|
NH
Kit
|
| 5. |
87055661
|
[2] |
TAPERED BEARING
|
BEL
Superseded by part number: 87668909
|
| 6. |
84271271
|
[1] |
BEVEL GEAR
|
NH
Crown, 29T
|
| 7. |
84227691
|
[1] |
OIL SEAL
|
NH
Double Lip
|
| 8. |
322496850
|
[1] |
DUST CAP
|
ZED
|
| 9. |
84271994
|
[1] |
BALL BEARING
|
NH
Superseded by part number: 66801
|
| 10. |
84271290
|
[1] |
GEARBOX
|
NH
|
| 11. |
86539148
|
[1] |
CAP
|
NH
|
| 12. |
86539215
|
[2] |
KIT
|
NH
Shim
|
| 13. |
86557412
|
[3] |
PLUG,3/8" - 19 NPT
|
NH
|
| 14. |
86557433
|
[1] |
TAPERED BEARING,40mm ID x 80mm OD x 24.75mm W
|
NH
|
| 15. |
86539153
|
[1] |
SEAL,40mm ID x 80mm OD x 10mm Thk
|
NH
|
| 16. |
84271481
|
[1] |
PINION
|
NH
Pinion, 15T
|
| 17. |
84271975
|
[1] |
SNAP RING
|
NH
Superseded by part number: 700714951
|
| 18. |
84271510
|
[1] |
COVER
|
NH
Output Shaft
|
| 19. |
84271518
|
[1] |
SHAFT
|
NH
|
| 20. |
86539157
|
[1] |
BREATHER,3/8" Gas
|
NH
|
| 21. |
87055892
|
[1] |
SHIM
|
BEL
Superseded by part number: 86623231
|
